242PC250G

Active

Honeywell Sensing and Productivity Solutions

SENSOR 250PSIG 1/8"NPT 6V

Search across all available documentation for this part.

Active

Honeywell Sensing and Productivity Solutions

SENSOR 250PSIG 1/8"NPT 6V

Technical Specifications

Parameters and characteristics for this part

Specification	242PC250G

Accuracy	0.5 %
Applications	Board Mount
Features	Temperature Compensated, Amplified Output
Maximum Pressure [Max]	500 PSI
Maximum Pressure [Max]	3447.38 kPa
Operating Pressure	250 PSI
Operating Pressure	1723.69 kPa
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Output [Max]	6 V
Output [Min]	1 V
Output Type	Analog Voltage
Package / Case	Module
Port Size	0.125 "
Port Size	3.18 mm
Port Size	Male
Port Style	Threaded
Pressure Type	Vented Gauge
Termination Style	Wire Leads
Voltage - Supply [Max]	16 V
Voltage - Supply [Min]	7 V

Part	Voltage - Supply [Min]	Voltage - Supply [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Pressure	Operating Pressure	Package / Case	Features	Output Type	Accuracy	Output [Min]	Output [Max]	Maximum Pressure [Max]	Maximum Pressure [Max]	Pressure Type	Termination Style	Applications	Port Size	Port Size	Port Size	Port Style
Honeywell Sensing and Productivity Solutions 242PC250G	7 V	16 V	85 °C	-40 °C	250 PSI	1723.69 kPa	Module	Amplified Output Temperature Compensated	Analog Voltage	0.5 %	1 V	6 V	500 PSI	3447.38 kPa	Vented Gauge	Wire Leads	Board Mount	0.125 "	3.18 mm	Male	Threaded

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	30	$ 1819.57

General part information

Pressure Sensor 250PSI (1723.69kPa) Vented Gauge Male - 1/8" (3.18mm) NPT 1 V ~ 6 V Module
