05R-JWPF-HHLE-D
ActiveJST Sales America Inc.
CONN RCPT HSG 5POS 2.00MM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
05R-JWPF-HHLE-D
ActiveJST Sales America Inc.
CONN RCPT HSG 5POS 2.00MM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 05R-JWPF-HHLE-D |
|---|---|
| Color | Gray |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Female Socket |
| Fastening Type | Latch Lock |
| Features | JIS C 0920 Grade Level 7 |
| Insulation Material | Polybutylene Terephthalate (PBT) |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Rows | 2 |
| Pitch [x] | 0.079 in |
| Pitch [x] | 2 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 1.73 | |
| 10 | $ 1.50 | |||
| 100 | $ 1.34 | |||
| 1000 | $ 0.96 | |||
| 5000 | $ 0.85 | |||
| 10000 | $ 0.83 | |||
Description
General part information
05R-JWPF Series
5 Rectangular Connectors - Housings Receptacle Gray 0.079" (2.00mm)
