3GBJ3508-BP

Active

Micro Commercial Components

BRIDGE RECTIFIER DIODE,

Search across all available documentation for this part.

Active

Micro Commercial Components

BRIDGE RECTIFIER DIODE,

Technical Specifications

Parameters and characteristics for this part

Specification	3GBJ3508-BP

Current - Average Rectified (Io)	35 A
Current - Reverse Leakage @ Vr	10 µA
Diode Type	Single Phase
Mounting Type	Through Hole
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-55 °C
Package / Case	5-SIP, TSB-5
Supplier Device Package	TSB-5
Technology	Standard
Voltage - Forward (Vf) (Max) @ If	1.1 V
Voltage - Peak Reverse (Max) [Max]	800 V

Part	Current - Average Rectified (Io)	Supplier Device Package	Mounting Type	Voltage - Peak Reverse (Max) [Max]	Technology	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Forward (Vf) (Max) @ If	Diode Type	Current - Reverse Leakage @ Vr
Micro Commercial Components 3GBJ3508-BP	35 A	TSB-5	Through Hole	800 V	Standard	5-SIP TSB-5	-55 °C	150 °C	1.1 V	Single Phase	10 µA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	960	$ 2.50

General part information

Bridge Rectifier Single Phase Standard 800 V Through Hole TSB-5

Technical documentation and resources

No documents available
