LQH3NPZ2R2MJRL

Active

Murata Power Solutions Inc.

FIXED IND

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

LQH3NPZ2R2MJRL

Active

Murata Power Solutions Inc.

FIXED IND

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	LQH3NPZ2R2MJRL

null

LQH3NPZ Series

Part	Current Rating (Amps)	Current - Saturation (Isat)	Inductance Frequency - Test	Mounting Type	Supplier Device Package	Supplier Device Package	Tolerance	Frequency - Self Resonant	Material - Core	Shielding	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Ratings	Package / Case	Package / Case	Type	Inductance	DC Resistance (DCR) [Max]	DC Resistance (DCR)	Height - Seated (Max) [Max] [z]
Murata Power Solutions Inc. LQH3NPZR68NJRL
Murata Power Solutions Inc. LQH3NPZ1R5MGRL	1.22 A	1.4 A	1 MHz	Surface Mount	3030 Metric	1212	20 %	80 MHz	Ferrite	Shielded	0.039 "	1 mm	-40 °C	105 ░C	0.118 in	3 mm	3 mm	0.118 in	AEC-Q200	1212	3030 Metric	Drum Core Wirewound	1.5 µH
Murata Power Solutions Inc. LQH3NPZ2R2MJRL
Murata Power Solutions Inc. LQH3NPZ220MGRL	450 mA	390 mA	1 MHz	Surface Mount	3030 Metric	1212	20 %	10 MHz	Ferrite	Shielded	0.039 "	1 mm	-40 °C	105 ░C	0.118 in	3 mm	3 mm	0.118 in	AEC-Q200	1212	3030 Metric	Drum Core Wirewound	22 µH	636 mOhm
Murata Power Solutions Inc. LQH3NPZ6R8MGRL	0.68 A	720 mA	1 MHz	Surface Mount	3030 Metric	1212	20 %	25 MHz	Ferrite	Shielded	0.039 "	1 mm	-40 °C	105 ░C	0.118 in	3 mm	3 mm	0.118 in	AEC-Q200	1212	3030 Metric	Drum Core Wirewound	6.8 µH		276 mOhm
Murata Power Solutions Inc. LQH3NPZ330MJRL
Murata Power Solutions Inc. LQH3NPZ1R0MMEL	3 A		1 MHz	Surface Mount	3030 Metric	1212	20 %	100 MHz	Ferrite	Shielded		1.5 mm	-40 °C	105 ░C	0.118 in	3 mm	3 mm	0.118 in	AEC-Q200	1212	3030 Metric	Drum Core Wirewound	1 µH	30 mOhm		0.059 "
Murata Power Solutions Inc. LQH3NPZ100MGRL	0.67 A	570 mA	1 MHz	Surface Mount	3030 Metric	1212	20 %	20 MHz	Ferrite	Shielded	0.039 "	1 mm	-40 °C	105 ░C	0.118 in	3 mm	3 mm	0.118 in	AEC-Q200	1212	3030 Metric	Drum Core Wirewound	10 µH	336 mOhm
Murata Power Solutions Inc. LQH3NPZ220MMEL	0.86 A		1 MHz	Surface Mount	3030 Metric	1212	20 %	10 MHz	Ferrite	Shielded		1.5 mm	-40 °C	105 ░C	0.118 in	3 mm	3 mm	0.118 in	AEC-Q200	1212	3030 Metric	Drum Core Wirewound	22 µH		480 mOhm	0.059 "
Murata Power Solutions Inc. LQH3NPZ6R8MJRL

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	2000	$ 0.21

Description

General part information

LQH3NPZ Series

Inductor
