QGKF-200-48
ActiveQualtek
AC/DC CONVERTER 48V 200W
Deep-Dive with AI
Search across all available documentation for this part.
QGKF-200-48
ActiveQualtek
AC/DC CONVERTER 48V 200W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | QGKF-200-48 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CB, cURus, CE |
| Current - Output 1 | 4.2 A |
| Efficiency | 87.5 % |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Power (Watts) | 200 W |
| Size / Dimension [x] | 7.83 in |
| Size / Dimension [x] | 199 mm |
| Size / Dimension [y] | 3.9 in |
| Size / Dimension [y] | 99 mm |
| Size / Dimension [z] | 50 mm |
| Size / Dimension [z] | 1.97 " |
| Type | Enclosed |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 48 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 100 | $ 81.28 | |
Description
General part information
QGKF-200 Series
Enclosed AC DC Converters 1 Output 48V 85 ~ 264 VAC Input
