943-SP-370808M2-A285
ActiveBEL MAGNETIC SOLUTIONS
943-SP-370808M2-A285
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
943-SP-370808M2-A285
ActiveBEL MAGNETIC SOLUTIONS
943-SP-370808M2-A285
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 943-SP-370808M2-A285 |
|---|---|
| Cable Type | Round Cable, Solid, Stranded Wires |
| Color | Translucent - Clear |
| Connector Type | Plug |
| Contact Finish | Gold |
| Contact Finish Thickness | 50 µin |
| Contact Finish Thickness | 1.27 µm |
| Contact Material | Phosphor Bronze |
| Current Rating (Amps) | 1.5 A |
| Housing Material | Polycarbonate (PC) |
| Length | 22.48 mm |
| Length | 0.885 in |
| Number of Positions/Contacts | 8p8c (RJ45, Ethernet) |
| Ratings | Cat5 |
| Shielding | Unshielded |
| Termination | IDC |
| Voltage Rating | 150 VDC |
943-SP-37 Series
| Part | Housing Material | Color | Length [x] | Length [x] | Features | Shield Material | Cable Type | Voltage Rating | Contact Finish | Number of Positions/Contacts | Contact Finish Thickness | Contact Finish Thickness | Current Rating (Amps) | Connector Type | Contact Material | Shielding | Termination | Ratings | Length | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
BEL MAGNETIC SOLUTIONS | Polycarbonate (PC) | Translucent - Clear | 26.16 mm | 1.03 in | Molded Boot | Brass | Round Cable Solid Stranded Wires | 150 VDC | Gold | 8p8c (RJ45 Ethernet) | 50 µin | 1.27 µm | 1.5 A | Plug | Phosphor Bronze | Shielded | IDC | Cat5 | |||
BEL MAGNETIC SOLUTIONS | Polycarbonate (PC) | Translucent - Clear | Molded Boot | Brass | Round Cable Solid Stranded Wires | 150 VDC | Gold | 8p8c (RJ45 Ethernet) | 50 µin | 1.27 µm | 1.5 A | Plug | Phosphor Bronze | Shielded | IDC | Cat5 | 1.286 in | 32.66 mm | |||
BEL MAGNETIC SOLUTIONS | Polycarbonate (PC) | Brass | Flat Oval Cable Solid or Stranded Wires | 150 VDC | Gold | 8p8c (RJ45 Ethernet) | 1.5 A | Plug | Copper Alloy | Unshielded | IDC | ||||||||||
BEL MAGNETIC SOLUTIONS | Polycarbonate (PC) | Translucent - Clear | Brass | Round Cable Solid Stranded Wires | 150 VDC | Gold | 8p8c (RJ45 Ethernet) | 50 µin | 1.27 µm | 1.5 A | Plug | Phosphor Bronze | Shielded | IDC | Cat5 | 0.95 " | 24.13 mm | ||||
BEL MAGNETIC SOLUTIONS | Polycarbonate (PC) | Translucent - Clear | Molded Boot | Brass | Round Cable Solid Stranded Wires | 150 VDC | Gold | 8p8c (RJ45 Ethernet) | 50 µin | 1.27 µm | 1.5 A | Plug | Phosphor Bronze | Shielded | IDC | Cat5 | 1.286 in | 32.66 mm | |||
BEL MAGNETIC SOLUTIONS | Polycarbonate (PC) | Translucent - Clear | Brass | Round Cable Solid Stranded Wires | 150 VDC | Gold | 8p8c (RJ45 Ethernet) | 50 µin | 1.27 µm | 1.5 A | Plug | Phosphor Bronze | Shielded | IDC | Cat5 | 0.95 " | 24.13 mm | ||||
BEL MAGNETIC SOLUTIONS | Polycarbonate (PC) | Translucent - Clear | Molded Boot | Brass | Round Cable Solid Stranded Wires | 150 VDC | Gold | 8p8c (RJ45 Ethernet) | 50 µin | 1.27 µm | 1.5 A | Plug | Phosphor Bronze | Shielded | IDC | Cat5 | 1.286 in | 32.66 mm | |||
BEL MAGNETIC SOLUTIONS | Polycarbonate (PC) | Translucent - Clear | Round Cable Solid Stranded Wires | 150 VDC | Gold | 8p8c (RJ45 Ethernet) | 50 µin | 1.27 µm | 1.5 A | Plug | Phosphor Bronze | Unshielded | IDC | Cat5 | 0.885 in | 22.48 mm | |||||
BEL MAGNETIC SOLUTIONS | Polycarbonate (PC) | Translucent - Clear | Round Cable Solid Stranded Wires | 150 VDC | Gold | 8p8c (RJ45 Ethernet) | 50 µin | 1.27 µm | 1.5 A | Plug | Phosphor Bronze | Unshielded | IDC | Cat5 | 0.885 in | 22.48 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
943-SP-37 Series
943-SP-370808M2-A285
