2032-14TSU

Active

Oupiin

CONN FFC VERT 14POS 2.54MM PCB

Search across all available documentation for this part.

Active

Oupiin

CONN FFC VERT 14POS 2.54MM PCB

Technical Specifications

Parameters and characteristics for this part

Specification	2032-14TSU

Cable End Type	Straight
Connector/Contact Type	Contacts, Vertical - 1 Sided
Contact Finish	Tin
Contact Finish Thickness	0.76 Ám
Contact Finish Thickness	30 Áin
Contact Material	Phosphor Bronze
Current Rating (Amps)	3 A
FFC, FCB Thickness	0.3 mm
Flat Flex Type	FPC, FFC
Height Above Board	6.7 mm
Height Above Board	0.264 "
Housing Color	Black
Housing Material	Polybutylene Terephthalate (PBT)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	14
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-25 °C
Pitch [x]	2.54 mm
Pitch [x]	0.1 in
Termination	Solder
Voltage Rating	250 VDC

Part	Voltage Rating	Pitch [x]	Pitch [x]	Flat Flex Type	Housing Material	Cable End Type	FFC, FCB Thickness	Material Flammability Rating	Mounting Type	Contact Finish	Housing Color	Contact Finish Thickness	Contact Finish Thickness	Number of Positions	Connector/Contact Type	Contact Material	Termination	Height Above Board	Height Above Board	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]
Oupiin 2032-14TSU	250 VDC	2.54 mm	0.1 in	FFC FPC	Polybutylene Terephthalate (PBT)	Straight	0.3 mm	UL94 V-0	Through Hole	Tin	Black	0.76 Ám	30 Áin	14	Contacts Vertical - 1 Sided	Phosphor Bronze	Solder	6.7 mm	0.264 "	3 A	-25 °C	85 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

14 Position FFC, FPC Connector Contacts, Vertical - 1 Sided 0.100" (2.54mm) Through Hole
