Q-1U0440005003M
ActiveAmphenol Custom Cable
CBL ASSY SMP-NTYPE PLG-JACK 9.8'
Deep-Dive with AI
Search across all available documentation for this part.
Q-1U0440005003M
ActiveAmphenol Custom Cable
CBL ASSY SMP-NTYPE PLG-JACK 9.8'
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | Q-1U0440005003M |
|---|---|
| 1st Connector | SMP Plug |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 1st Contact Gender | Male |
| 2nd Connector | N-Type Jack |
| 2nd Connector Mounting Feature | Bulkhead - Front Side Nut |
| 2nd Connector Mounting Type | Panel Mount |
| 2nd Contact Gender | Female |
| Cable Type | RG-316 |
| Color | Copper |
| Features | Shielded |
| Frequency - Max [Max] | 11 GHz |
| Length | 3 m |
| Length | 118.1 in |
| Length | 9.8 ' |
| Overall Impedance | 50 Ohms |
| Style | SMP to N-Type |
Q-1U0440 Series
| Part | Cable Type | 1st Contact Gender | Features | Color | Style | Frequency - Max [Max] | 1st Connector | 2nd Contact Gender | Length | Length | Length | 2nd Connector Mounting Feature | 1st Connector Mounting Type | 2nd Connector Mounting Type | 2nd Connector | Overall Impedance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol Custom Cable | RG-316 | Male | Shielded | Copper | SMP to N-Type | 11 GHz | SMP Plug | Female | 6 ft | 72 in | 1.8 m | Bulkhead - Front Side Nut | Free Hanging (In-Line) | Panel Mount | N-Type Jack | 50 Ohms |
Amphenol Custom Cable | RG-174 | Male | Shielded | Black | SMP to N-Type | 11 GHz | SMP Plug | Female | 4 ft | 48 in | 1200 mm | Bulkhead - Front Side Nut | Free Hanging (In-Line) | Panel Mount | N-Type Jack | 50 Ohms |
Amphenol Custom Cable | RG-316 | Male | Shielded | Copper | SMP to N-Type | 11 GHz | SMP Plug | Female | 5 ft | 5 ' | 1.5 m | Bulkhead - Front Side Nut | Free Hanging (In-Line) | Panel Mount | N-Type Jack | 50 Ohms |
Amphenol Custom Cable | RG-174 | Male | Shielded | Black | SMP to N-Type | 11 GHz | SMP Plug | Female | 9 ft | 108 in | 2.7 m | Bulkhead - Front Side Nut | Free Hanging (In-Line) | Panel Mount | N-Type Jack | 50 Ohms |
Amphenol Custom Cable | RG-174 | Male | Shielded | Black | SMP to N-Type | 11 GHz | SMP Plug | Female | 7 ft | 84 in | 2.1 m | Bulkhead - Front Side Nut | Free Hanging (In-Line) | Panel Mount | N-Type Jack | 50 Ohms |
Amphenol Custom Cable | RG-174 | Male | Shielded | Black | SMP to N-Type | 11 GHz | SMP Plug | Female | 29.53 " | 750 mm | Bulkhead - Front Side Nut | Free Hanging (In-Line) | Panel Mount | N-Type Jack | 50 Ohms | |
Amphenol Custom Cable | RG-316 | Male | Shielded | Copper | SMP to N-Type | 11 GHz | SMP Plug | Female | 8.2 ' | 98.4 in | 2.5 m | Bulkhead - Front Side Nut | Free Hanging (In-Line) | Panel Mount | N-Type Jack | 50 Ohms |
Amphenol Custom Cable | RG-316 | Male | Shielded | Copper | SMP to N-Type | 11 GHz | SMP Plug | Female | 9.8 ' | 118.1 in | 3 m | Bulkhead - Front Side Nut | Free Hanging (In-Line) | Panel Mount | N-Type Jack | 50 Ohms |
Amphenol Custom Cable | RG-174 | Male | Shielded | Black | SMP to N-Type | 11 GHz | SMP Plug | Female | 9 " | 228.6 mm | Bulkhead - Front Side Nut | Free Hanging (In-Line) | Panel Mount | N-Type Jack | 50 Ohms | |
Amphenol Custom Cable | RG-316 | Male | Shielded | Copper | SMP to N-Type | 11 GHz | SMP Plug | Female | 3 in | 76.2 mm | Bulkhead - Front Side Nut | Free Hanging (In-Line) | Panel Mount | N-Type Jack | 50 Ohms |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 137.66 | |
| 25 | $ 128.35 | |||
| 50 | $ 119.04 | |||
| 100 | $ 111.05 | |||
| 250 | $ 104.40 | |||
Description
General part information
Q-1U0440 Series
Cable Assembly Coaxial SMP to N-Type RG-316 118.1" (3.0m) 9.8'
