FC2131-0000-0010-L

Obsolete

TE Connectivity Measurement Specialties

SENSOR FORCE LOAD CELL 10LBS

Search across all available documentation for this part.

Obsolete

TE Connectivity Measurement Specialties

SENSOR FORCE LOAD CELL 10LBS

Technical Specifications

Parameters and characteristics for this part

Specification	FC2131-0000-0010-L

Accuracy	1 %
Actuator Style/Size	Round
Actuator Style/Size	5 mm
Actuator Type	Pushbutton
Compensated Temperature [Max]	50 °C
Compensated Temperature [Min]	0 °C
Includes	Sensor
Operating Force	10 lbs
Operating Force	4.54 kgf
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Output [Max]	4.5 V
Output [Min]	0.5 V
Sensor Type	Load Cell
Voltage - Supply [Max]	5 V
Voltage - Supply [Min]	3.3 V

Part	Actuator Type	Actuator Style/Size	Actuator Style/Size	Accuracy	Voltage - Supply [Max]	Voltage - Supply [Min]	Includes	Operating Force	Operating Force	Sensor Type	Output [Min]	Output [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Compensated Temperature [Min]	Compensated Temperature [Max]
TE Connectivity Measurement Specialties FC2131-0000-0010-L	Pushbutton	Round	5 mm	1 %	5 V	3.3 V	Sensor	10 lbs	4.54 kgf	Load Cell	0.5 V	4.5 V	85 °C	-40 °C	0 °C	50 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

SENSOR FORCE LOAD CELL 10LBS

Technical documentation and resources
