PTC34SAEN

Obsolete

Sullins Connector Solutions

CONN HEADER VERT 34POS 2.54MM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

PTC34SAEN

Obsolete

Sullins Connector Solutions

CONN HEADER VERT 34POS 2.54MM

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	PTC34SAEN

Connector Type	Header
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	2.54 çm
Contact Finish Thickness - Mating	100 çin
Contact Finish Thickness - Post	2.54 µm
Contact Finish Thickness - Post	100 µin
Contact Length - Mating	5.84 mm
Contact Length - Mating [x]	0.23 in
Contact Length - Post	13.21 mm
Contact Length - Post	0.52 "
Contact Material	Copper Alloy
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	3 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.1 in
Insulation Height	2.54 mm
Insulation Material	Polyester, Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	34
Number of Positions Loaded	All
Number of Rows	1
Overall Contact Length	0.85 in
Overall Contact Length	21.59 mm
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Shrouding	Unshrouded
Style	Board to Board, Cable
Termination	Solder

PTC34 Series

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Pitch - Mating	Pitch - Mating	Material Flammability Rating	Contact Length - Post [x]	Contact Length - Post [x]	Current Rating (Amps)	Insulation Material	Shrouding	Contact Finish - Post	Number of Rows	Style	Contact Material	Insulation Color	Connector Type	Number of Positions	Fastening Type	Contact Shape	Insulation Height	Insulation Height	Termination	Contact Length - Mating [x]	Contact Length - Mating	Contact Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions Loaded	Mounting Type	Overall Contact Length	Overall Contact Length	Contact Length - Mating [x]	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Length - Post	Contact Length - Post
Sullins Connector Solutions PTC34SBDN	2.54 µm	100 µin	0.1 in	2.54 mm	UL94 V-0	10.67 mm	0.42 in	3 A	Polyester Thermoplastic	Unshrouded	Tin	1	Board to Board Cable	Copper Alloy	Black	Header	34	Push-Pull	Square	3.56 mm	0.14 in	Solder	0.23 in	5.84 mm	Male Pin	2.54 çm	100 çin	All	Through Hole Right Angle
Sullins Connector Solutions PTC34DFCN	2.54 µm	100 µin	0.1 in	2.54 mm	UL94 V-0	8.13 mm	0.32 in	3 A	Polyester Thermoplastic	Unshrouded	Tin	2	Board to Board Cable	Copper Alloy	Black	Header	68	Push-Pull	Square	2.54 mm	0.1 in	Solder	0.318 "		Male Pin	2.54 çm	100 çin	All	Through Hole	0.738 "	18.75 mm	8.08 mm	2.54 mm	0.1 in
Sullins Connector Solutions PTC34SAEN	2.54 µm	100 µin	0.1 in	2.54 mm	UL94 V-0			3 A	Polyester Thermoplastic	Unshrouded	Tin	1	Board to Board Cable	Copper Alloy	Black	Header	34	Push-Pull	Square	2.54 mm	0.1 in	Solder	0.23 in	5.84 mm	Male Pin	2.54 çm	100 çin	All	Through Hole	0.85 in	21.59 mm				13.21 mm	0.52 "
Sullins Connector Solutions PTC34DAFN	2.54 µm	100 µin	0.1 in	2.54 mm	UL94 V-0			3 A	Polyester Thermoplastic	Unshrouded	Tin	2	Board to Board Cable	Copper Alloy	Black	Header	68	Push-Pull	Square	2.54 mm	0.1 in	Solder	0.23 in	5.84 mm	Male Pin	2.54 çm	100 çin	All	Through Hole	0.95 in	24.13 mm		2.54 mm	0.1 in	15.75 mm	0.62 in
Sullins Connector Solutions PTC34DBAN	2.54 µm	100 µin	0.1 in	2.54 mm	UL94 V-0	3.05 mm	0.12 in	3 A	Polyester Thermoplastic	Unshrouded	Tin	2	Board to Board Cable	Copper Alloy	Black	Header	68	Push-Pull	Square	6.1 mm	0.24 in	Solder	0.23 in	5.84 mm	Male Pin	2.54 çm	100 çin	All	Through Hole Right Angle				2.54 mm	0.1 in
Sullins Connector Solutions PTC34SBBN	2.54 µm	100 µin	0.1 in	2.54 mm	UL94 V-0			3 A	Polyester Thermoplastic	Unshrouded	Tin	1	Board to Board Cable	Copper Alloy	Black	Header	34	Push-Pull	Square	3.56 mm	0.14 in	Solder	0.23 in	5.84 mm	Male Pin	2.54 çm	100 çin	All	Through Hole Right Angle						5.84 mm	0.23 in
Sullins Connector Solutions PTC34SAFN	2.54 µm	100 µin	0.1 in	2.54 mm	UL94 V-0			3 A	Polyester Thermoplastic	Unshrouded	Tin	1	Board to Board Cable	Copper Alloy	Black	Header	34	Push-Pull	Square	2.54 mm	0.1 in	Solder	0.23 in	5.84 mm	Male Pin	2.54 çm	100 çin	All	Through Hole	0.95 in	24.13 mm				15.75 mm	0.62 in
Sullins Connector Solutions PTC34SBEN	2.54 µm	100 µin	0.1 in	2.54 mm	UL94 V-0			3 A	Polyester Thermoplastic	Unshrouded	Tin	1	Board to Board Cable	Copper Alloy	Black	Header	34	Push-Pull	Square	3.56 mm	0.14 in	Solder	0.23 in	5.84 mm	Male Pin	2.54 çm	100 çin	All	Through Hole Right Angle						13.21 mm	0.52 "
Sullins Connector Solutions PTC34DBCN	2.54 µm	100 µin	0.1 in	2.54 mm	UL94 V-0	8.13 mm	0.32 in	3 A	Polyester Thermoplastic	Unshrouded	Tin	2	Board to Board Cable	Copper Alloy	Black	Header	68	Push-Pull	Square	6.1 mm	0.24 in	Solder	0.23 in	5.84 mm	Male Pin	2.54 çm	100 çin	All	Through Hole Right Angle				2.54 mm	0.1 in
Sullins Connector Solutions PTC34DFBN	2.54 µm	100 µin	0.1 in	2.54 mm	UL94 V-0			3 A	Polyester Thermoplastic	Unshrouded	Tin	2	Board to Board Cable	Copper Alloy	Black	Header	68	Push-Pull	Square	2.54 mm	0.1 in	Solder	0.318 "		Male Pin	2.54 çm	100 çin	All	Through Hole	0.638 in	16.21 mm	8.08 mm	2.54 mm	0.1 in	5.58 mm	0.22 in
