856-10-006-30-002000

Active

Mill-Max Manufacturing Corp.

CONN SPRING TARGET 6POS SMD

Search across all available documentation for this part.

Active

Mill-Max Manufacturing Corp.

CONN SPRING TARGET 6POS SMD

Technical Specifications

Parameters and characteristics for this part

Part	Pitch [x]	Pitch [x]	Connector Type	Number of Contacts [custom]	Number of Rows	Contact Finish Thickness	Contact Finish Thickness	Mounting Type	Contact Finish	Material	Number of Contacts
Mill-Max Manufacturing Corp. 856-10-006-20-002000	0.05 in	1.27 mm	Mating Target	6	1	10 Áin	0.25 Ám	Surface Mount Right Angle	Gold	Brass Alloy
Mill-Max Manufacturing Corp. 856-10-010-10-002000	0.05 in	1.27 mm	Mating Target		1	10 Áin	0.25 Ám	Through Hole	Gold	Brass Alloy	10
Mill-Max Manufacturing Corp. 856-10-005-30-051000	0.05 in	1.27 mm	Mating Target		1	10 Áin	0.25 Ám	Surface Mount	Gold	Brass Alloy	5
Mill-Max Manufacturing Corp. 856-10-006-30-002000	0.05 in	1.27 mm	Mating Target	6	1	10 Áin	0.25 Ám	Surface Mount	Gold	Brass Alloy
Mill-Max Manufacturing Corp. 856-10-019-40-002000	0.05 in	1.27 mm	Mating Target	19	1	10 Áin	0.25 Ám	Surface Mount Right Angle	Gold	Brass Alloy
Mill-Max Manufacturing Corp. 856-10-012-10-002000	0.05 in	1.27 mm	Mating Target		1	10 Áin	0.25 Ám	Through Hole	Gold	Brass Alloy	12
Mill-Max Manufacturing Corp. 856-10-013-10-002000	0.05 in	1.27 mm	Mating Target		1	10 Áin	0.25 Ám	Through Hole	Gold	Brass Alloy	13
Mill-Max Manufacturing Corp. 856-10-009-40-001000	0.05 in	1.27 mm	Mating Target		1	10 Áin	0.25 Ám	Surface Mount Right Angle	Gold	Brass Alloy	9
Mill-Max Manufacturing Corp. 856-10-001-40-002000			Mating Target		1	10 Áin	0.25 Ám	Surface Mount Right Angle	Gold	Brass Alloy	1
Mill-Max Manufacturing Corp. 856-10-013-30-051000	0.05 in	1.27 mm	Mating Target		1	10 Áin	0.25 Ám	Surface Mount	Gold	Brass Alloy	13

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	65	$ 11.45

General part information

6 Position Spring Mating Target Connector Surface Mount

Technical documentation and resources

No documents available
