AMED30-48SNZ

Active

aimtec

AC/DC DIN RAIL SUPPLY 2X48V 36W

Search across all available documentation for this part.

Active

aimtec

AC/DC DIN RAIL SUPPLY 2X48V 36W

Technical Specifications

Parameters and characteristics for this part

Specification	AMED30-48SNZ

AC Voltage - Input [Max]	264 VAC
AC Voltage - Input [Min]	85 VAC
Applications	ITE (Commercial)
Current - Output (Max) [Max]	750 mA
DC Voltage - Input (Max) [Max]	264 V
DC Voltage - Input (Min) [Min]	85 V
Efficiency	90 %
Features	Adjustable Output, Universal Input
Input Type	AC or DC
Minimum Load Required	False
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-40 °C
Power (Watts)	36 W
Size / Dimension [x]	57.9 mm
Size / Dimension [x]	2.28 in
Size / Dimension [y]	35.1 mm
Size / Dimension [y]	1.38 "
Size / Dimension [z]	92.7 mm
Size / Dimension [z]	3.65 in
Standard Number	62368-1
Voltage - Isolation	4000 V
Voltage - Output 1	48 V

Part	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	AC Voltage - Input [Min]	AC Voltage - Input [Max]	DC Voltage - Input (Max) [Max]	Voltage - Isolation	Number of Outputs	Operating Temperature [Min]	Operating Temperature [Max]	Features	Applications	Voltage - Output 1	Efficiency	Input Type	DC Voltage - Input (Min) [Min]	Power (Watts)	Standard Number	Current - Output (Max) [Max]
aimtec AMED30-48SNZ	35.1 mm	1.38 "	92.7 mm	3.65 in	57.9 mm	2.28 in	85 VAC	264 VAC	264 V	4000 V	1	-40 °C	70 °C	Adjustable Output Universal Input	ITE (Commercial)	48 V	90 %	AC or DC	85 V	36 W	62368-1	750 mA
aimtec AMED30-24SNZ	35 mm	1.38 "	92.7 mm	3.65 in	58 mm	2.28 in	85 VAC	264 VAC	370 V	4000 V	1	-40 °C	70 °C	Universal Input	ITE (Commercial)	24 V	89 %	AC or DC	120 V	36 W		1.5 A
aimtec AMED30-12SNZ	35 mm	1.38 "	92.7 mm	3.65 in	58 mm	2.28 in	85 VAC	264 VAC	370 V	4000 V	1	-40 °C	70 °C	Universal Input	ITE (Commercial)	12 V	88 %	AC or DC	120 V	24 W		2 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

AC/DC DIN RAIL SUPPLY 2X48V 36W
