166L25B
ActiveHammond Manufacturing
PWR XFMR LAMINATED 50.4VA CHAS
Deep-Dive with AI
Search across all available documentation for this part.
166L25B
ActiveHammond Manufacturing
PWR XFMR LAMINATED 50.4VA CHAS
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 166L25B |
|---|---|
| Center Tap | True |
| Current - Output (Max) [Max] | 2 A |
| Height - Seated (Max) [Max] [z] | 66.8 mm |
| Mounting Type | Chassis Mount |
| Power - Max [Max] | 50.4 VA |
| Primary Winding(s) | Single |
| Secondary Winding(s) | Single |
| Size / Dimension [x] | 102.36 mm |
| Size / Dimension [y] | 2.25 in |
| Termination Style | Wire Leads |
| Type | Laminated Core |
| Voltage - Isolation | 2000 Vrms |
| Voltage - Secondary (Full Load) | 25.2 V |
| Weight | 952.5 g |
| Weight | 2.1 lb |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 45.86 | |
Description
General part information
166L25 Series
PWR XFMR LAMINATED 50.4VA CHAS
Documents
Technical documentation and resources
No documents available
