FSSL072ND

Active

Belden Inc.

CBL FIBER OPTIC

Search across all available documentation for this part.

Active

Belden Inc.

CBL FIBER OPTIC

Technical Specifications

Parameters and characteristics for this part

Specification	FSSL072ND

Cladding Diameter [diameter]	125 µm
Core Diameter [diameter]	9 µm
Features	72 Fibers
Features	Rip Cord
Jacket (Insulation) Diameter [diameter]	0.403 in
Jacket (Insulation) Diameter [diameter]	10.23 mm
Jacket (Insulation) Material	Polyethylene (PE)
Jacket Color	Black
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-40 °C
Style	Multiple Fibers
Tensile Strength	81.6 kg
Type	Singlemode

Part	Features	Features	Operating Temperature [Min]	Operating Temperature [Max]	Tensile Strength	Cladding Diameter [diameter]	Jacket Color	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Type	Style	Core Diameter [diameter]	Jacket (Insulation) Material
Belden Inc. FSSL072ND	72 Fibers	Rip Cord	-40 °C	70 °C	81.6 kg	125 µm	Black	0.403 in	10.23 mm	Singlemode	Multiple Fibers	9 µm	Polyethylene (PE)
Belden Inc. FSSL072NG	72 Fibers	Rip Cord	-40 °C	70 °C	81.6 kg	125 µm	Black	0.427 in	10.85 mm	Singlemode	Multiple Fibers	9 µm	Polyethylene (PE)
Belden Inc. FSSL0726G	72 Fibers	Rip Cord Steel Armor	-40 °C	70 °C	81.6 kg	125 µm	Black	0.61 "	15.49 mm	Singlemode	Multiple Fibers	9 µm	Poly-Vinyl Chloride (PVC)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1	$ 2.73

General part information

Fiber Optic Cable Black Singlemode 125µm
