530-26-06-BL-0250F

Active

CnC Tech, LLC

CABLE MOD FLAT 6COND REEL 250'

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

530-26-06-BL-0250F

Active

CnC Tech, LLC

CABLE MOD FLAT 6COND REEL 250'

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	530-26-06-BL-0250F

Cable Height	0.097 in
Cable Height	2.46 mm
Cable Type	Straight
Cable Width	0.267 in
Cable Width	6.8 mm
Conductor Material	Copper, Bare
Conductor Strand [x]	7
Conductor Strand [y]	0.0063 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket Color	Black
Length [x]	76.2 m
Length [x]	250 ft
Number of Conductors	6
Shielding	Unshielded
Wire Gauge	26 AWG

530-26 Series

Part	Conductor Strand [x]	Conductor Strand [y]	Cable Type	Number of Conductors	Cable Width	Cable Width	Conductor Material	Length [x]	Length [x]	Cable Height	Cable Height	Jacket Color	Shielding	Wire Gauge	Jacket (Insulation) Material	Length	Cable Width
CnC Tech, LLC 530-26-04-BL-0250F	7	0.0063 in	Straight	4	0.189 in	4.8 mm	Copper Bare	76.2 m	250 ft	0.097 in	2.46 mm	Black	Unshielded	26 AWG	Poly-Vinyl Chloride (PVC)
CnC Tech, LLC 530-26-10-BL-0100F	7	0.0063 in	Straight	10	0.425 in	10.8 mm	Copper Bare		100 ft	0.097 in	2.46 mm	Black	Unshielded	26 AWG	Poly-Vinyl Chloride (PVC)	30.5 m
CnC Tech, LLC 530-26-08-SV-0500F	7	0.0063 in	Straight	8	0.346 in	8.8 mm	Copper Bare	152.4 m	500 '	0.097 in	2.46 mm	Silver	Unshielded	26 AWG	Poly-Vinyl Chloride (PVC)
CnC Tech, LLC 530-26-06-BL-0250F	7	0.0063 in	Straight	6		0.267 in	Copper Bare	76.2 m	250 ft	0.097 in	2.46 mm	Black	Unshielded	26 AWG	Poly-Vinyl Chloride (PVC)		6.8 mm
CnC Tech, LLC 530-26-10-SV-0250F	7	0.0063 in	Straight	10	0.425 in	10.8 mm	Copper Bare	76.2 m	250 ft	0.097 in	2.46 mm	Silver	Unshielded	26 AWG	Poly-Vinyl Chloride (PVC)
CnC Tech, LLC 530-26-10-WH-0100F	7	0.0063 in	Straight	10	0.425 in	10.8 mm	Copper Bare		100 ft	0.097 in	2.46 mm		Unshielded	26 AWG	Poly-Vinyl Chloride (PVC)	30.5 m
CnC Tech, LLC 530-26-08-SV-0100F	7	0.0063 in	Straight	8	0.346 in	8.8 mm	Copper Bare		100 ft	0.097 in	2.46 mm	Silver	Unshielded	26 AWG	Poly-Vinyl Chloride (PVC)	30.5 m
CnC Tech, LLC 530-26-06-WH-0250F	7	0.0063 in	Straight	6		0.267 in	Copper Bare	76.2 m	250 ft	0.097 in	2.46 mm		Unshielded	26 AWG	Poly-Vinyl Chloride (PVC)		6.8 mm
CnC Tech, LLC 530-26-04-BL-0500F	7	0.0063 in	Straight	4	0.189 in	4.8 mm	Copper Bare	152.4 m	500 '	0.097 in	2.46 mm	Black	Unshielded	26 AWG	Poly-Vinyl Chloride (PVC)
CnC Tech, LLC 530-26-04-SV-0500F	7	0.0063 in	Straight	4	0.189 in	4.8 mm	Copper Bare	152.4 m	500 '	0.097 in	2.46 mm	Silver	Unshielded	26 AWG	Poly-Vinyl Chloride (PVC)

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1	$ 80.12
		3	$ 74.12
		5	$ 71.55
		7	$ 69.84
		10	$ 68.12
		25	$ 63.84
		50	$ 60.41
		100	$ 57.84

Description

General part information

530-26 Series

6 Conductor Modular Straight Cable Black 250' (76.20m)

Documents

Technical documentation and resources
