NB-PTCO-191
ActiveTE Connectivity Measurement Specialties
SENSOR RTD 1KOHM 2SIP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
NB-PTCO-191
ActiveTE Connectivity Measurement Specialties
SENSOR RTD 1KOHM 2SIP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | NB-PTCO-191 |
|---|---|
| Accuracy | 0.3 °C |
| Current | 400 µA |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 300 °C |
| Operating Temperature [Min] | -30 ░C |
| Package / Case | 2-SIP |
| Resistance @ 0°C | 1000 Ohms |
| Resistance Tolerance | 0.12 % |
| RTD Material | Platinum (Pt) |
| Temperature Coefficient | 3850 ppm/°C |
| Termination | PC Pins |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 5.27 | |
| 10 | $ 3.95 | |||
| 25 | $ 3.51 | |||
| 50 | $ 3.34 | |||
| 100 | $ 3.25 | |||
| 500 | $ 2.72 | |||
| 1000 | $ 2.55 | |||
Description
General part information
NB-PTCO Series
1 kOhms RTD Platinum (Pt) 3850ppm/°C 2-SIP
