SM700K10L
ActiveANYSOLAR Ltd
MONOCRY SOLAR CELL 154.3MW 6.91V
Deep-Dive with AI
Search across all available documentation for this part.
SM700K10L
ActiveANYSOLAR Ltd
MONOCRY SOLAR CELL 154.3MW 6.91V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SM700K10L |
|---|---|
| Current - Short Circuit (Isc) | 29.5 mA |
| Current @ Pmpp | 27.7 mA |
| Operating Temperature [Max] | 90 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Cells |
| Power (Watts) - Max [Max] | 154.3 mW |
| Size / Dimension [x] | 0.945 " |
| Size / Dimension [x] | 24 mm |
| Size / Dimension [y] | 36 mm |
| Size / Dimension [y] | 1.417 " |
| Size / Dimension [z] | 0.071 " |
| Size / Dimension [z] | 1.8 mm |
| Type | Monocrystalline |
| Voltage @ Pmpp | 5.58 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 6.91 | |
| 10 | $ 5.86 | |||
| 50 | $ 5.23 | |||
| 100 | $ 4.97 | |||
| 250 | $ 4.66 | |||
| 500 | $ 4.44 | |||
| 1000 | $ 4.22 | |||
Description
General part information
SM700 Series
Monocrystalline Solar Cell 154.3 mW 6.91 V
Documents
Technical documentation and resources
No documents available
