ME-XU8-4CG-1E-D11E-R2.1
ObsoleteEnclustra FPGA Solutions
SOM ZYNQ US+ ZU4CG 2GB+2GB PL
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ME-XU8-4CG-1E-D11E-R2.1
ObsoleteEnclustra FPGA Solutions
SOM ZYNQ US+ ZU4CG 2GB+2GB PL
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | ME-XU8-4CG-1E-D11E-R2.1 |
|---|---|
| Connector Type | 168 Pin |
| Flash Size | 16 GB |
| Module/Board Type | FPGA Core, MPU |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | 0 °C |
| RAM Size | 2 GB, 1 GB |
| Size / Dimension [x] | 2.91 " |
| Size / Dimension [x] | 74 mm |
| Size / Dimension [y] | 54 mm |
| Size / Dimension [y] | 2.13 in |
| Speed | 533 MHz |
| Speed | 1.333 GHz |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
ME-XU8 Series
- Embedded Module ARM® Quad-Core Cortex-A53, ARM® Dual-Core Cortex-R5, Mali-400MP2 GPU 533MHz, 1.333GHz 1GB, 2GB 16GB
