19352 010250

Active

Belden Inc.

CABLE 3COND 18AWG BLACK 250'

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 3COND 18AWG BLACK 250'

Technical Specifications

Parameters and characteristics for this part

Specification	19352 010250

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Bare
Conductor Strand	34 AWG, 42
Jacket (Insulation) Diameter [diameter]	8.33 mm
Jacket (Insulation) Diameter [diameter]	0.328 "
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.046 in
Jacket (Insulation) Thickness	1.168 mm
Jacket Color	Black
Length	3000 "
Length	76.2 m
Number of Conductors	3
Operating Temperature	60 °C
Wire Gauge	18 AWG

Part	Operating Temperature	Cable Type	Conductor Strand	Jacket (Insulation) Material	Wire Gauge	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Number of Conductors	Length	Length	Conductor Insulation	Jacket Color
Belden Inc. 19352 010250	60 °C	Multi-Conductor	34 AWG 42	Poly-Vinyl Chloride (PVC)	18 AWG	0.046 in	1.168 mm	Copper Bare	8.33 mm	0.328 "	3	3000 "	76.2 m	Poly-Vinyl Chloride (PVC)	Black

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Conductor Multi-Conductor Cable Black 18 AWG 250.0' (76.2m)
