DDR-240C-48

Active

MEAN WELL USA Inc.

DC/DC DIN RAIL SUPPLY 48V 240W

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

DC/DC DIN RAIL SUPPLY 48V 240W

Technical Specifications

Parameters and characteristics for this part

Specification	DDR-240C-48

Applications	Railway, ITE (Commercial)
Approval Agency	CE, EAC
Current - Output (Max) [Max]	5 A
DC Voltage - Input (Max) [Max]	67.2 V
DC Voltage - Input (Min) [Min]	33.6 V
Efficiency	92 %
Features	Load Sharing, Remote On/Off, Adjustable Output
Input Type	DC
Number of Outputs	1
Power (Watts)	240 W
Size / Dimension [x]	113.5 mm
Size / Dimension [x]	4.47 in
Size / Dimension [y]	1.57 "
Size / Dimension [y]	40 mm
Size / Dimension [z]	4.93 in
Size / Dimension [z]	125.2 mm
Voltage - Isolation	4000 V
Voltage - Output 1	48 V

Part	Voltage - Output 1	DC Voltage - Input (Min) [Min]	Current - Output (Max) [Max]	Power (Watts)	Number of Outputs	Input Type	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Applications	Efficiency	DC Voltage - Input (Max) [Max]	Approval Agency	Voltage - Isolation	Features
MEAN WELL USA Inc. DDR-240B-24	24 V	16.8 V	10 A	240 W	1	DC	4.93 in	1.57 "	113.5 mm	4.47 in	125.2 mm	40 mm	ITE (Commercial) Railway	90 %	33.6 V	CE EAC	4000 V	Adjustable Output Load Sharing Remote On/Off
MEAN WELL USA Inc. DDR-240C-48	48 V	33.6 V	5 A	240 W	1	DC	4.93 in	1.57 "	113.5 mm	4.47 in	125.2 mm	40 mm	ITE (Commercial) Railway	92 %	67.2 V	CE EAC	4000 V	Adjustable Output Load Sharing Remote On/Off
MEAN WELL USA Inc. DDR-240C-24	24 V	33.6 V	10 A	240 W	1	DC	4.93 in	1.57 "	113.5 mm	4.47 in	125.2 mm	40 mm	ITE (Commercial) Railway	91 %	67.2 V	CE EAC	4000 V	Adjustable Output Load Sharing Remote On/Off

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

DC/DC DIN RAIL SUPPLY 48V 240W
