ADC-04PMMS-SC7001

Active

Amphenol LTW

CERES, LARGE SIZE, PLASTIC, 20A, 04 PINS, MALE CONNECTOR, MALE CONTACT, CIRCULAR, SCREW THREAD, SOLDER, RECEPTACLE, IP67 ROHS CO

Search across all available documentation for this part.

Active

Amphenol LTW

CERES, LARGE SIZE, PLASTIC, 20A, 04 PINS, MALE CONNECTOR, MALE CONTACT, CIRCULAR, SCREW THREAD, SOLDER, RECEPTACLE, IP67 ROHS CO

Technical Specifications

Parameters and characteristics for this part

Specification	ADC-04PMMS-SC7001

Color	Black
Connector Type	Receptacle, Male Pins
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	20 A
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Front Side Nut
Number of Positions	4
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	D
Shielding	Unshielded
Voltage Rating	250 VAC

Part	Contact Finish - Mating	Connector Type	Number of Positions	Orientation	Voltage Rating	Current Rating (Amps)	Shell Material	Mounting Feature	Shielding	Color	Operating Temperature [Min]	Operating Temperature [Max]	Primary Material	Ingress Protection	Contact Material	Shell Size - Insert	Material Flammability Rating	Insert Material
Amphenol LTW ADC-04PMMS-SC7001	Gold	Male Pins Receptacle	4	Keyed	250 VAC	20 A	Glass Filled Nylon Polyamide (PA)	Bulkhead - Front Side Nut	Unshielded	Black	-40 °C	105 ░C	Plastic	IP67 - Dust Tight Waterproof	Copper Alloy	D	UL94 V-0	Polyamide (PA) Nylon Glass Filled

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 Position Circular Connector Receptacle, Male Pins Solder Cup
