KMS30A-5
ActiveTDK-LAMBDA
AC/DC CONVERTER 5V 25W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
KMS30A-5
ActiveTDK-LAMBDA
AC/DC CONVERTER 5V 25W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | KMS30A-5 |
|---|---|
| Applications | ITE (Commercial), Medical |
| Approval Agency | CE, cURus |
| Current - Output (Max) [Max] | 5 A |
| Efficiency | 84 % |
| Features | Universal Input |
| Line Regulation | 25 mV |
| Load Regulation | 50 mV |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4 Lead |
| Package / Case | 5-DIP Module |
| Power (Watts) | 25 W |
| Size / Dimension [x] | 2.52 in |
| Size / Dimension [x] | 64 mm |
| Size / Dimension [y] | 45.6 mm |
| Size / Dimension [y] | 1.8 in |
| Size / Dimension [z] | 0.93 in |
| Size / Dimension [z] | 23.5 mm |
| Standard Number | 60950-1, 60601-1, 62368-1 |
| Type | Enclosed |
| Voltage - Input [Max] | 370 VDC, 264 VAC |
| Voltage - Input [Min] | 90 VAC, 120 VDC |
| Voltage - Output 1 | 5 V |
| Weight | 130.18 g |
| Weight | 0.287 lb |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 60.05 | |
| 10 | $ 56.05 | |||
| 25 | $ 55.39 | |||
Description
General part information
KMS30A Series
Enclosed AC DC Converters 1 Output 5V 5A 90 ~ 264 VAC, 120 ~ 370 VDC Input
