HBG-200-48A

Active

MEAN WELL USA Inc.

LED DVR CC/CV ACDC 28.8-48V 4.1A

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

LED DVR CC/CV ACDC 28.8-48V 4.1A

Technical Specifications

Parameters and characteristics for this part

Part	Ratings	Termination Style	Type	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Power (Watts)	Voltage - Output [Min]	Voltage - Output [Max]	Topology	Number of Outputs	Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Voltage - Isolation	Features	Approval Agency	Voltage - Input (Min) [Min]	Efficiency	Size / Dimension [diameter]	Size / Dimension [z]	Size / Dimension [diameter]	Size / Dimension [z]	Voltage - Output	Standard Number	Dimming
MEAN WELL USA Inc. HBG-200-48A	IP65	Wire Leads	Constant Current Voltage	Chassis Mount	85 °C	-40 °C	197 W	28.8 V	48 V	AC DC Converter	1	305 VAC	4.1 A	3750 V	OCP OTP OVP SCP	CB CCC CE cURus ENEC	90 VAC	93 %	151.7 mm	66.5 mm	5.97 in	2.62 in
MEAN WELL USA Inc. HBG-200-60DA	IP67	Wire Leads	Constant Current Voltage	Chassis Mount	85 °C	-40 °C	198 W			AC DC Converter	1	305 VAC	3.3 A	3750 V	OCP OTP OVP SCP	CB CCC CE cURus EAC ENEC	90 VAC	93.5 %	151.7 mm	66.5 mm	5.97 in	2.62 in	60 V	UL 8750	Analog PWM
MEAN WELL USA Inc. HBG-200-36A	IP65	Wire Leads	Constant Current Voltage	Chassis Mount	85 °C	-40 °C	198 W	21.6 V	36 V	AC DC Converter	1	305 VAC	5.5 A	3750 V	OCP OTP OVP SCP	CB CCC CE cURus ENEC	90 VAC	92 %	151.7 mm	66.5 mm	5.97 in	2.62 in
MEAN WELL USA Inc. HBG-200-60A	IP65	Wire Leads	Constant Current Voltage	Chassis Mount	85 °C	-40 °C	198 W	36 V	60 VDC	AC DC Converter	1	305 VAC	3.3 A	3750 V	OCP OTP OVP SCP	CB CCC CE cURus ENEC	90 VAC	93.5 %	151.7 mm	66.5 mm	5.97 in	2.62 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4.1A 28.8 ~ 48V Constant Current, Voltage LED Driver AC DC Converter Topology 1 Output
