832-10-030-30-001101

Active

PRECI-DIP SA

CONN HEADER SMD 30POS 2MM

Deep-Dive with AI

Search across all available documentation for this part.

832-10-030-30-001101

Active

PRECI-DIP SA

CONN HEADER SMD 30POS 2MM

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	832-10-030-30-001101

Connector Type	Header
Contact Finish - Mating	Gold
Contact Finish - Post	Gold
Contact Finish Thickness - Mating	10 çin
Contact Finish Thickness - Mating	0.25 çm
Contact Finish Thickness - Post	10 çin
Contact Finish Thickness - Post	0.25 çm
Contact Length - Mating	0.141 in
Contact Length - Mating	3.6 mm
Contact Material	Brass
Contact Shape	Circular
Contact Type	Male Pin
Current Rating (Amps)	3 A
Fastening Type	Push-Pull
Insulation Color	Black
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions	30
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating [x]	0.079 in
Pitch - Mating [x]	2 mm
Row Spacing - Mating	0.079 in
Row Spacing - Mating	2 mm
Shrouding	Unshrouded
Termination	Solder
Voltage Rating	150 VDC

832-10 Series

...

Part	Material Flammability Rating	Contact Shape	Shrouding	Termination	Operating Temperature [Min]	Operating Temperature [Max]	Pitch - Mating [x]	Pitch - Mating [x]	Overall Contact Length	Overall Contact Length	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions	Contact Length - Mating	Contact Length - Mating	Number of Rows	Mounting Type	Number of Positions Loaded	Voltage Rating	Fastening Type	Insulation Color	Contact Finish - Post	Contact Type	Current Rating (Amps)	Contact Finish - Mating	Connector Type	Row Spacing - Mating	Row Spacing - Mating	Contact Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Length - Post	Contact Length - Post	Insulation Height [z]	Insulation Height [z]	Contact Length - Post [x]
PRECI-DIP SA 832-10-068-10-001101	UL94 V-0	Circular	Unshrouded	Solder	-55 °C	125 °C	0.079 in	2 mm	10 mm	0.394 in	10 çin	0.25 çm	68	0.141 in	3.6 mm	2	Through Hole	All	150 VDC	Push-Pull	Black	Gold	Male Pin	3 A	Gold	Header	0.079 in	2 mm	Brass	10 çin	0.25 çm	0.114 in	2.9 mm
PRECI-DIP SA 832-10-094-30-001101	UL94 V-0	Circular	Unshrouded	Solder	-55 °C	125 °C	0.079 in	2 mm			10 çin	0.25 çm	94	0.141 in	3.6 mm	2	Surface Mount	All	150 VDC	Push-Pull	Black	Gold	Male Pin	3 A	Gold	Header	0.079 in	2 mm	Brass	10 çin	0.25 çm
PRECI-DIP SA 832-10-056-20-001101	UL94 V-0	Circular	Unshrouded	Solder	-55 °C	125 °C	0.079 in	2 mm			10 çin	0.25 çm	56	0.141 in	3.6 mm	2	Through Hole Right Angle	All	150 VDC	Push-Pull	Black	Gold	Male Pin	3 A	Gold	Header	0.079 in	2 mm	Brass	10 çin	0.25 çm		3.2 mm	0.165 in	4.2 mm	0.126 in
PRECI-DIP SA 832-10-074-10-001101	UL94 V-0	Circular	Unshrouded	Solder	-55 °C	125 °C	0.079 in	2 mm	10 mm	0.394 in	10 çin	0.25 çm	74	0.141 in	3.6 mm	2	Through Hole	All	150 VDC	Push-Pull	Black	Gold	Male Pin	3 A	Gold	Header	0.079 in	2 mm	Brass	10 çin	0.25 çm	0.114 in	2.9 mm
PRECI-DIP SA 832-10-086-20-001101	UL94 V-0	Circular	Unshrouded	Solder	-55 °C	125 °C	0.079 in	2 mm			10 çin	0.25 çm	86	0.141 in	3.6 mm	2	Through Hole Right Angle	All	150 VDC	Push-Pull	Black	Gold	Male Pin	3 A	Gold	Header	0.079 in	2 mm	Brass	10 çin	0.25 çm		3.2 mm	0.165 in	4.2 mm	0.126 in
PRECI-DIP SA 832-10-028-20-001101	UL94 V-0	Circular	Unshrouded	Solder	-55 °C	125 °C	0.079 in	2 mm			10 çin	0.25 çm	28	0.141 in	3.6 mm	2	Through Hole Right Angle	All	150 VDC	Push-Pull	Black	Gold	Male Pin	3 A	Gold	Header	0.079 in	2 mm	Brass	10 çin	0.25 çm		3.2 mm	0.165 in	4.2 mm	0.126 in
PRECI-DIP SA 832-10-030-30-001101	UL94 V-0	Circular	Unshrouded	Solder	-55 °C	125 °C	0.079 in	2 mm			10 çin	0.25 çm	30	0.141 in	3.6 mm	2	Surface Mount	All	150 VDC	Push-Pull	Black	Gold	Male Pin	3 A	Gold	Header	0.079 in	2 mm	Brass	10 çin	0.25 çm
PRECI-DIP SA 832-10-048-10-001101	UL94 V-0	Circular	Unshrouded	Solder	-55 °C	125 °C	0.079 in	2 mm	10 mm	0.394 in	10 çin	0.25 çm	48	0.141 in	3.6 mm	2	Through Hole	All	150 VDC	Push-Pull	Black	Gold	Male Pin	3 A	Gold	Header	0.079 in	2 mm	Brass	10 çin	0.25 çm	0.114 in	2.9 mm
PRECI-DIP SA 832-10-010-10-001101	UL94 V-0	Circular	Unshrouded	Solder	-55 °C	125 °C	0.079 in	2 mm	10 mm	0.394 in	10 çin	0.25 çm	10	0.141 in	3.6 mm	2	Through Hole	All	150 VDC	Push-Pull	Black	Gold	Male Pin	3 A	Gold	Header	0.079 in	2 mm	Brass	10 çin	0.25 çm	0.114 in	2.9 mm
PRECI-DIP SA 832-10-014-10-001101	UL94 V-0	Circular	Unshrouded	Solder	-55 °C	125 °C	0.079 in	2 mm	10 mm	0.394 in	10 çin	0.25 çm	14	0.141 in	3.6 mm	2	Through Hole	All	150 VDC	Push-Pull	Black	Gold	Male Pin	3 A	Gold	Header	0.079 in	2 mm	Brass	10 çin	0.25 çm	0.114 in	2.9 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	110	$ 7.22

Description

General part information

832-10 Series

Connector Header Surface Mount 30 position 0.079" (2.00mm)

Documents

Technical documentation and resources

No documents available
