TMV 1509DHI
ActiveTraco Power
DC DC CONVERTER +/-9V 1W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TMV 1509DHI
ActiveTraco Power
DC DC CONVERTER +/-9V 1W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TMV 1509DHI |
|---|---|
| Applications | ITE (Commercial) |
| Efficiency | 75 % |
| Features | SCP |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 95 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 7-SIP Module, 5 Leads |
| Size / Dimension [x] | 19.5 mm |
| Size / Dimension [x] | 0.77 in |
| Size / Dimension [y] | 7.5 mm |
| Size / Dimension [y] | 0.3 " |
| Size / Dimension [z] | 10.2 mm |
| Size / Dimension [z] | 0.4 " |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 16.5 V |
| Voltage - Input (Min) [Min] | 13.5 V |
| Voltage - Isolation | 5.2 kV |
| Voltage - Output 1 | 9 V |
| Voltage - Output 2 | -9 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 10 | $ 9.89 | |
Description
General part information
TMV 1509 Series
Isolated Module DC DC Converter 2 Output 9V -9V 56mA, 56mA 13.5V - 16.5V Input
