Technical Specifications
Parameters and characteristics for this part
| Specification | IBDN25R 006500 |
|---|---|
| Cable Type | Multi-Pair, Cat5e |
| Conductor Insulation | Polyolefin (PO) |
| Conductor Material | Copper, Bare |
| Conductor Strand | Solid |
| Features | Rip Cord |
| Jacket (Insulation) Diameter [diameter] | 0.51 in |
| Jacket (Insulation) Diameter [diameter] | 12.95 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC), Riser |
| Jacket Color | Blue |
| Length [x] | 500 ' |
| Length [x] | 152.4 m |
| Number of Conductors [custom] | 50 |
| Number of Conductors [custom] | 25 |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -30 ░C |
| Ratings | UL Style CMR |
| Usage | Network |
| Voltage | 300 V |
| Wire Gauge | 24 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
IBDN25R Series
50 (25 Pair) Conductor Multi-Pair, Cat5e Cable Blue 24 AWG 500.0' (152.4m)
Documents
Technical documentation and resources
