MT4B2AL

Active

Menics

COMPLETE UNIT GR/R STEADY 2STACK

Search across all available documentation for this part.

Active

Menics

COMPLETE UNIT GR/R STEADY 2STACK

Technical Specifications

Parameters and characteristics for this part

Specification	MT4B2AL

Function - Lighting	Steady
Ingress Protection	IP54 - Dust Protected, Water Resistant
Lamp Type	Incandescent
Light Color	Red, Green
Number of Stacks	2
Operating Temperature [Max]	40 °C
Operating Temperature [Min]	-15 °C
Termination Style	Wire Leads
Type	Complete Unit
Voltage - Supply	24 VAC

Part	Type	Voltage - Supply	Light Color	Termination Style	Function - Lighting	Operating Temperature [Min]	Operating Temperature [Max]	Lamp Type	Number of Stacks	Ingress Protection	Features	Voltage - Supply [Max]	Voltage - Supply [Min]
Menics MT4B5DL	Complete Unit	12 VAC	Blue Clear Green Red Yellow	Wire Leads	Steady	-15 °C	40 °C	Incandescent	5	IP54 - Dust Protected Water Resistant
Menics MT4B2AL	Complete Unit	24 VAC	Green Red	Wire Leads	Steady	-15 °C	40 °C	Incandescent	2	IP54 - Dust Protected Water Resistant
Menics MT4B5BL	Complete Unit	110 VAC/DC	Blue Clear Green Red Yellow	Wire Leads	Steady	-15 °C	40 °C	Incandescent	5	IP54 - Dust Protected Water Resistant
Menics ATES-R	Complete Unit	110 VAC/DC	Red	Cable with Connector	Flashing	-15 °C	40 °C		1		Selector Control
Menics PTM-A-102-RYG-B	Complete Unit	24 VAC	Green Red Yellow	Wire Leads	Steady	-15 °C	40 °C		1	IP65 - Dust Tight Water Resistant
Menics ATES-G	Complete Unit	110 VAC/DC	Green	Cable with Connector	Steady	-15 °C	40 °C		1		Selector Control
Menics MT4B2DL	Complete Unit	12 VAC	Green Red	Wire Leads	Steady	-15 °C	40 °C	Incandescent	2	IP54 - Dust Protected Water Resistant
Menics PTM-A-1FF-RYG-B	Complete Unit		Green Red Yellow	Wire Leads	Steady	-15 °C	40 °C		1	IP65 - Dust Tight Water Resistant		240 VAC	90 VAC
Menics PTM-A-1FF-RBG-B	Complete Unit		Blue Green Red	Wire Leads	Steady	-15 °C	40 °C		1	IP65 - Dust Tight Water Resistant		240 VAC	90 VAC
Menics ATEP-R	Complete Unit	110 VAC/DC	Red	Cable with Connector	Flashing	-15 °C	40 °C		1		Pushbutton Control

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 36.90
