Technical Specifications
Parameters and characteristics for this part
| Specification | STD03205 |
|---|---|
| Load Current | 2.5 A |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Output Type | DC |
| Package / Case | 4-SIP |
| Supplier Device Package | 4-SIP |
| Termination Style | PC Pin |
| Voltage - Input | 24 V |
| Voltage - Load [Max] | 30 V |
| Voltage - Load [Min] | 0 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 34.26 | |
Description
General part information
STD032 Series
Solid State SPST-NO (1 Form A) 4-SIP
