FAD1-12038EBHW12

Active

Qualtek

FAN AXIAL 120X38.5MM 48VDC WIRE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet AC/DC Axial Fans

FAD1-12038EBHW12

Active

Qualtek

FAN AXIAL 120X38.5MM 48VDC WIRE

Deep-Dive with AI

DocumentsDatasheet AC/DC Axial Fans

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	FAD1-12038EBHW12

Air Flow	2.95 m³/min
Air Flow	105.5 CFM
Approval Agency	cURus, CE, TUV
Bearing Type	Ball
Current Rating (Amps)	0.18 A
Fan Type	Tubeaxial
Material - Blade	Plastic
Material - Frame	Plastic
Noise	46.7 dB(A)
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-10 °C
Operating Temperature [Min]	-10 °C
Power (Watts)	8.64 W
RPM	2800 RPM
Size / Dimension [x]	120 mm
Size / Dimension [y]	120 mm
Static Pressure	0.265 in H2O
Static Pressure	66 Pa
Termination	2 Wire Leads
Voltage - Rated [custom]	48 VDC
Voltage Range [Max]	52.8 VDC
Voltage Range [Min]	43.2 VDC
Weight	0.518 lb
Weight	234.96 g
Width [y]	38.5 mm

FAD1-12038 Series

Part	Static Pressure	Static Pressure	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Termination	Air Flow	Air Flow	Power (Watts)	Fan Type	Weight	Weight	Material - Blade	Approval Agency	Bearing Type	Voltage Range [Min]	Voltage Range [Max]	Size / Dimension [y]	Size / Dimension [x]	Current Rating (Amps)	Material - Frame	Noise	Width [y]	Voltage - Rated [custom]	RPM	Voltage - Rated
Qualtek FAD1-12038EBHW12	0.265 in H2O	66 Pa	70 °C	70 °C	-10 °C	-10 °C	2 Wire Leads	2.95 m³/min	105.5 CFM	8.64 W	Tubeaxial	0.518 lb	234.96 g	Plastic	CE cURus TUV	Ball	43.2 VDC	52.8 VDC	120 mm	120 mm	0.18 A	Plastic	46.7 dB(A)	38.5 mm	48 VDC	2800 RPM
Qualtek FAD1-12038EBJW32	0.335 in H2O	83.4 Pa	70 °C	70 °C	-10 °C	-10 °C	2 Wire Leads	3.36 m³/min	120.1 CFM	10.56 W	Tubeaxial	0.656 lb	297.56 g	Plastic	CE cURus TUV	Ball	43.2 VDC	52.8 VDC	120 mm	120 mm	0.22 A	Aluminum	48 dB	38.5 mm	48 VDC	3200 RPM
Qualtek FAD1-12038DBHW12	0.265 in H2O	66 Pa	70 °C	70 °C	-10 °C	-10 °C	2 Wire Leads	2.95 m³/min	105.5 CFM	6.24 W	Tubeaxial	0.518 lb	234.96 g	Plastic	CE cURus TUV	Ball	21.6 VDC	26.4 VDC	120 mm	120 mm	0.26 A	Plastic	46.7 dB(A)	38.5 mm		2800 RPM	24 VDC
Qualtek FAD1-12038DBMW12	0.228 in H2O	56.8 Pa	70 °C	70 °C	-10 °C	-10 °C	2 Wire Leads	2.7 m³/min	96.3 CFM	4.8 W	Tubeaxial	0.518 lb	234.96 g	Plastic	CE cURus TUV	Ball	21.6 VDC	26.4 VDC	120 mm	120 mm	0.2 A	Plastic	45 dB(A)	38.5 mm		2540 RPM	24 VDC
Qualtek FAD1-12038EBJW12	0.335 in H2O	83.4 Pa	70 °C	70 °C	-10 °C	-10 °C	2 Wire Leads	3.36 m³/min	120.1 CFM	10.6 W	Tubeaxial	0.518 lb	234.96 g	Plastic	CE cURus TUV	Ball	43.2 VDC	52.8 VDC	120 mm	120 mm	0.22 A	Plastic	48 dB	38.5 mm	48 VDC	3200 RPM

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 12.66

Description

General part information

FAD1-12038 Series

Fan Tubeaxial 48VDC Square - 120mm L x 120mm H Ball 105.5 CFM (2.95m³/min) 2 Wire Leads
