851-83-035-40-252101

Active

PRECI-DIP SA

CONN SOCKET 35P 0.05 GOLD SMD RA

Deep-Dive with AI

Search across all available documentation for this part.

851-83-035-40-252101

Active

PRECI-DIP SA

CONN SOCKET 35P 0.05 GOLD SMD RA

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	851-83-035-40-252101

Connector Type	Socket
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	29.5 Áin
Contact Finish Thickness - Mating	0.75 Ám
Contact Material	Beryllium Copper
Contact Shape	Circular
Contact Type	Female Socket
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.087 "
Insulation Height	2.2 mm
Insulation Material	Polyester, Glass Filled, Polycyclohexylenedimethylene Terephthalate (PCT)
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount, Right Angle
Number of Positions	35
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating	0.05 in
Pitch - Mating	1.27 mm
Termination	Solder

851-83 Series

...

Part	Mounting Type	Contact Finish - Mating	Pitch - Mating	Pitch - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Material Flammability Rating	Contact Shape	Insulation Height	Insulation Height	Number of Positions	Contact Material	Termination	Contact Length - Post	Contact Length - Post	Connector Type	Number of Positions Loaded	Number of Rows	Insulation Color	Fastening Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Material	Contact Type	Contact Finish - Post	Features
PRECI-DIP SA 851-83-012-10-001101	Through Hole	Gold	0.05 in	1.27 mm	-55 °C	125 °C	UL94 V-0	Circular	0.161 in	4.1 mm	12	Beryllium Copper	Solder	0.091 in	2.3 mm	Socket	All	1	Black	Push-Pull	29.5 Áin	0.75 Ám	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Female Socket	Tin
PRECI-DIP SA 851-83-006-20-001101	Through Hole Right Angle	Gold	0.05 in	1.27 mm	-55 °C	125 °C	UL94 V-0	Circular	0.087 "	2.2 mm	6	Beryllium Copper	Solder	0.118 in	3 mm	Socket	All	1	Black	Push-Pull	29.5 Áin	0.75 Ám	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Female Socket	Tin
PRECI-DIP SA 851-83-006-40-252191	Surface Mount Right Angle	Gold	0.05 in	1.27 mm	-55 °C	125 °C	UL94 V-0	Circular	0.087 "	2.2 mm	6	Beryllium Copper	Solder			Socket	All	1	Black	Push-Pull	29.5 Áin	0.75 Ám	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Female Socket	Tin
PRECI-DIP SA 851-83-007-30-136101	Surface Mount	Gold	0.05 in	1.27 mm	-55 °C	125 °C	UL94 V-0	Circular	0.203 in	5.16 mm	7	Beryllium Copper	Solder			Socket	All	1	Black	Push-Pull	29.5 Áin	0.75 Ám	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Female Socket	Tin	Board Guide
PRECI-DIP SA 851-83-018-20-001101	Through Hole Right Angle	Gold	0.05 in	1.27 mm	-55 °C	125 °C	UL94 V-0	Circular	0.087 "	2.2 mm	18	Beryllium Copper	Solder	0.118 in	3 mm	Socket	All	1	Black	Push-Pull	29.5 Áin	0.75 Ám	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Female Socket	Tin
PRECI-DIP SA 851-83-019-30-136101	Surface Mount	Gold	0.05 in	1.27 mm	-55 °C	125 °C	UL94 V-0	Circular	0.203 in	5.16 mm	19	Beryllium Copper	Solder			Socket	All	1	Black	Push-Pull	29.5 Áin	0.75 Ám	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Female Socket	Tin	Board Guide
PRECI-DIP SA 851-83-046-20-001101	Through Hole Right Angle	Gold	0.05 in	1.27 mm	-55 °C	125 °C	UL94 V-0	Circular	0.087 "	2.2 mm	46	Beryllium Copper	Solder	0.118 in	3 mm	Socket	All	1	Black	Push-Pull	29.5 Áin	0.75 Ám	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Female Socket	Tin
PRECI-DIP SA 851-83-035-40-252101	Surface Mount Right Angle	Gold	0.05 in	1.27 mm	-55 °C	125 °C	UL94 V-0	Circular	0.087 "	2.2 mm	35	Beryllium Copper	Solder			Socket	All	1	Black	Push-Pull	29.5 Áin	0.75 Ám	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Female Socket	Tin
PRECI-DIP SA 851-83-018-40-252101	Surface Mount Right Angle	Gold	0.05 in	1.27 mm	-55 °C	125 °C	UL94 V-0	Circular	0.087 "	2.2 mm	18	Beryllium Copper	Solder			Socket	All	1	Black	Push-Pull	29.5 Áin	0.75 Ám	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Female Socket	Tin
PRECI-DIP SA 851-83-011-10-001101	Through Hole	Gold	0.05 in	1.27 mm	-55 °C	125 °C	UL94 V-0	Circular	0.161 in	4.1 mm	11	Beryllium Copper	Solder	0.091 in	2.3 mm	Socket	All	1	Black	Push-Pull	29.5 Áin	0.75 Ám	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Female Socket	Tin

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	90	$ 8.41

Description

General part information

851-83 Series

35 Position Socket Connector 0.050" (1.27mm) Surface Mount, Right Angle Gold

Documents

Technical documentation and resources

No documents available
