C44BXFP3470ZA0J

Active

KEMET

CAP FILM 0.47UF 5% 2.4KVDC RAD

Search across all available documentation for this part.

Active

KEMET

CAP FILM 0.47UF 5% 2.4KVDC RAD

Technical Specifications

Parameters and characteristics for this part

Specification	C44BXFP3470ZA0J

Applications	Snubber
Capacitance	0.47 µF
Dielectric Material	Metallized, Polypropylene (PP)
ESR (Equivalent Series Resistance)	2.5 mOhms
Height - Seated (Max) [Max]	107 mm
Height - Seated (Max) [Max]	4.213 in
Lead Spacing	22.3 mm
Lead Spacing	0.878 in
Mounting Type	Chassis, Stud Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can
Size / Dimension [diameter]	45 mm
Size / Dimension [diameter]	1.772 in
Termination	Threaded, Male
Tolerance	5 %
Voltage Rating - AC	1 kV
Voltage Rating - AC	1 kV
Voltage Rating - DC	2.4 kV
Voltage Rating - DC	2400 V

Part	Mounting Type	Voltage Rating - AC	Voltage Rating - AC	Tolerance	Capacitance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Lead Spacing	Lead Spacing	Applications	Termination	Dielectric Material	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [diameter]	Size / Dimension [diameter]	ESR (Equivalent Series Resistance)	Voltage Rating - DC	Voltage Rating - DC	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KEMET C44BXFP3470ZA0J	Chassis Stud Mount	1 kV	1 kV	5 %	0.47 µF	107 mm	4.213 in	22.3 mm	0.878 in	Snubber	Threaded Male	Metallized Polypropylene (PP)	Radial Can	85 °C	-40 °C	45 mm	1.772 in	2.5 mOhms	2.4 kV	2400 V
KEMET C44BXFP3220ZC0J	Chassis Stud Mount	1 kV	1 kV	5 %	0.22 µF			22.3 mm	0.878 in	Snubber	Threaded Male	Metallized Polypropylene (PP)	Radial Can	85 °C	-40 °C	45 mm	1.772 in	2.5 mOhms	2.4 kV	2400 V	3.15 in	80 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

0.47 µF Film Capacitor 1000V (1kV) 2400V (2.4kV) Polypropylene (PP), Metallized Radial, Can
