3KP10A_R2_00001

Active

Panjit International Inc.

SURFACE MOUNT TRANSIENT VOLTAGE

Search across all available documentation for this part.

Active

Panjit International Inc.

SURFACE MOUNT TRANSIENT VOLTAGE

Technical Specifications

Parameters and characteristics for this part

Specification	3KP10A_R2_00001

Applications	General Purpose
Current - Peak Pulse (10/1000µs)	176.4 A
Mounting Type	Through Hole
Operating Temperature [Max]	175 ░C
Operating Temperature [Min]	-55 °C
Package / Case	P600, Axial
Power - Peak Pulse	3000 W
Power - Peak Pulse	3 kW
Power Line Protection	False
Supplier Device Package	P600
Type	Zener
Unidirectional Channels [custom]	1
Voltage - Breakdown (Min) [Min]	11.1 V
Voltage - Clamping (Max) @ Ipp [Max]	17 V
Voltage - Reverse Standoff (Typ)	10 V

Part	Power - Peak Pulse	Power - Peak Pulse	Unidirectional Channels [custom]	Package / Case	Current - Peak Pulse (10/1000µs)	Supplier Device Package	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Breakdown (Min) [Min]	Mounting Type	Type	Voltage - Reverse Standoff (Typ)	Applications	Power Line Protection	Voltage - Clamping (Max) @ Ipp [Max]
Panjit International Inc. 3KP10A_R2_00001	3000 W	3 kW	1	P600 Axial	176.4 A	P600	-55 °C	175 ░C	11.1 V	Through Hole	Zener	10 V	General Purpose		17 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

17V Clamp 176.4A Ipp Tvs Diode Through Hole P600
