SK1-076C04
ActiveAnderson Power Products, Inc.
CONN PLUG 4POS IN-LINE CRIMP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SK1-076C04
ActiveAnderson Power Products, Inc.
CONN PLUG 4POS IN-LINE CRIMP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SK1-076C04 |
|---|---|
| Connector Type | Non-Gendered |
| Current Rating (Amps) | 40 A |
| Fastening Type | Spring Retention |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 4 |
| Number of Rows | 2 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Termination | Crimp |
| Voltage Rating | 600 V |
| Wire Gauge [Max] | 24 AWG |
| Wire Gauge [Min] | 6 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 24.34 | |
| 10 | $ 21.32 | |||
| 25 | $ 20.40 | |||
| 50 | $ 19.74 | |||
| 100 | $ 19.08 | |||
| 250 | $ 18.03 | |||
| 500 | $ 17.50 | |||
Description
General part information
SK1-076C Series
4 Position Non-Gendered Connector Crimp Free Hanging (In-Line)
