MOV20V210Y
ActiveEaton - Electronics Division
VARISTOR 210 VAC 20MM DISC
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MOV20V210Y
ActiveEaton - Electronics Division
VARISTOR 210 VAC 20MM DISC
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MOV20V210Y |
|---|---|
| Capacitance @ Frequency | 1200 pF |
| Energy | 150 J |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Disc 20mm |
| Varistor Voltage (Max) [Max] | 363 V |
| Varistor Voltage (Min) [Min] | 297 V |
| Varistor Voltage (Typ) | 330 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 1.00 | |
| 10 | $ 0.62 | |||
| 25 | $ 0.52 | |||
| 100 | $ 0.41 | |||
| 250 | $ 0.36 | |||
| 500 | $ 0.32 | |||
| 1000 | $ 0.29 | |||
| 2500 | $ 0.26 | |||
| 5000 | $ 0.25 | |||
Description
General part information
MOV20 Series
330 V 6.5 kA Varistor 1 Circuit Through Hole Disc 20mm
Documents
Technical documentation and resources
