3314S-1-104E

Active

Bourns Inc.

TRIMMER 100K OHM 0.25W J LEAD

Search across all available documentation for this part.

Active

Bourns Inc.

TRIMMER 100K OHM 0.25W J LEAD

Technical Specifications

Parameters and characteristics for this part

Part	Mounting Type	Number of Turns	Resistive Material	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Termination Style	Adjustment Type	Power (Watts)	Power (Watts)	Tolerance	Resistance	Temperature Coefficient
Bourns Inc. 3314S-2-502E	Surface Mount	1	Cermet	0.197 in	0.177 "	5 mm	4.5 mm	J Lead	Side Adjustment	0.25 W	250 mW	20 %	5 kOhms	100 ppm/°C
Bourns Inc. 3314S-1-104E	Surface Mount	1	Cermet	0.197 in	0.177 "	5 mm	4.5 mm	J Lead	Side Adjustment	0.25 W	250 mW	20 %	100 kOhms	100 ppm/°C
Bourns Inc. 3314S-2-100E	Surface Mount	1	Cermet	0.197 in	0.177 "	5 mm	4.5 mm	J Lead	Side Adjustment	0.25 W	250 mW	20 %	10 Ohms	100 ppm/°C
Bourns Inc. 3314S-2-204E	Surface Mount	1	Cermet	0.197 in	0.177 "	5 mm	4.5 mm	J Lead	Side Adjustment	0.25 W	250 mW	20 %	200000 Ohms	100 ppm/°C
Bourns Inc. 3314S-1-102G	Surface Mount	1	Cermet	0.197 in	0.177 "	5 mm	4.5 mm	J Lead	Side Adjustment	0.25 W	250 mW	20 %	1000 Ohms	100 ppm/°C
Bourns Inc. 3314S-3-203E	Surface Mount	1	Cermet	0.197 in	0.177 "	5 mm	4.5 mm	J Lead	Side Adjustment	0.25 W	250 mW	20 %	20 kOhms	100 ppm/°C
Bourns Inc. 3314S-3-254E	Surface Mount	1	Cermet	0.197 in	0.177 "	5 mm	4.5 mm	J Lead	Side Adjustment	0.25 W	250 mW	20 %	250 kOhms	100 ppm/°C
Bourns Inc. 3314S-1-101G	Surface Mount	1	Cermet	0.197 in	0.177 "	5 mm	4.5 mm	J Lead	Side Adjustment	0.25 W	250 mW	20 %	100 Ohms	100 ppm/°C
Bourns Inc. 3314S-1-203G	Surface Mount	1	Cermet	0.197 in	0.177 "	5 mm	4.5 mm	J Lead	Side Adjustment	0.25 W	250 mW	20 %	20 kOhms	100 ppm/°C
Bourns Inc. 3314S-2-501E	Surface Mount	1	Cermet	0.197 in	0.177 "	5 mm	4.5 mm	J Lead	Side Adjustment	0.25 W	250 mW	20 %	500 Ohms	100 ppm/°C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

100 kOhms 0.25W, 1/4W J Lead Surface Mount Trimmer Potentiometer Cermet 1.0 Turn Side Adjustment
