COM-13999
ActiveSparkFun Electronics
DISPLAY 7SEG 0.56" DBL RGB 14DIP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
COM-13999
ActiveSparkFun Electronics
DISPLAY 7SEG 0.56" DBL RGB 14DIP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | COM-13999 |
|---|---|
| Color | Red, Green, Blue |
| Digit/Alpha Size | 0.56 in |
| Digit/Alpha Size | 14.22 mm |
| Display Type | 7-Segment |
| Millicandela Rating [custom] | 70 mcd |
| Millicandela Rating [custom] | 21.7 mcd |
| Millicandela Rating [custom] | 21.7 mcd |
| Number of Characters | 2 |
| Package / Case | 0.6 in |
| Package / Case | 14-DIP |
| Package / Case | 15.24 mm |
| Power Dissipation (Max) [Max] | 150 mW |
| Size / Dimension [x] | 19.05 mm |
| Size / Dimension [x] | 0.75 in |
| Size / Dimension [y] | 25 mm |
| Size / Dimension [y] | 0.984 in |
| Size / Dimension [z] | 8 mm |
| Size / Dimension [z] | 0.315 " |
| Voltage - Forward (Vf) (Typ) [custom] | 2 V |
| Voltage - Forward (Vf) (Typ) [custom] | 2.85 V |
| Voltage - Forward (Vf) (Typ) [custom] | 2.95 V |
| Wavelength - Peak [custom] | 464 nm |
| Wavelength - Peak [custom] | 629 nm |
| Wavelength - Peak [custom] | 520 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 4.50 | |
Description
General part information
COM-139 Series
Display Modules - LED Character and Numeric Red, Green, Blue (RGB) 7-Segment 2 Character 2V Red, 2.85V Green, 2.95V Blue 0.750" H x 0.984" W x 0.315" D (19.05mm x 25.00mm x 8.00mm) 14-DIP (0.600", 15.24mm)
