PSC126-7IR
ActiveEOS Power India Private Ltd
DC/DC CONVERTER 12V 72W
Deep-Dive with AI
Search across all available documentation for this part.
PSC126-7IR
ActiveEOS Power India Private Ltd
DC/DC CONVERTER 12V 72W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | PSC126-7IR |
|---|---|
| Applications | Railway, ITE (Commercial) |
| Approval Agency | cCSAus, CE |
| Current - Output (Max) [Max] | 6 A |
| Efficiency | 89 % |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 71 °C |
| Operating Temperature [Min] | -25 °C |
| Power (Watts) | 72 W |
| Size / Dimension [x] | 5.94 in |
| Size / Dimension [x] | 151 mm |
| Size / Dimension [y] | 32.2 mm |
| Size / Dimension [y] | 1.27 in |
| Size / Dimension [z] | 88 mm |
| Size / Dimension [z] | 3.46 " |
| Type | Conformal Coated, Enclosed |
| Voltage - Input (Max) [Max] | 144 V |
| Voltage - Input (Min) [Min] | 18 V |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 606.00 | |
| 10 | $ 575.70 | |||
Description
General part information
PSC126 Series
Enclosed, Conformal Coated DC DC Converter 1 Output 12V 6A 144V Input
