811-S1-016-10-016101

Active

PRECI-DIP SA

CONN SPRING PISTON 16POS PCB

Search across all available documentation for this part.

Active

PRECI-DIP SA

CONN SPRING PISTON 16POS PCB

Technical Specifications

Parameters and characteristics for this part

...

Part	Material	Number of Rows	Contact Finish	Pitch [x]	Pitch [x]	Number of Contacts	Mounting Type	Contact Finish Thickness	Contact Finish Thickness	Connector Type	Number of Contacts [custom]	Number of Contacts [custom]
PRECI-DIP SA 811-S1-062-10-015101	Brass	1	Gold	2.54 mm	0.1 in	62	Through Hole	19.7 µin	0.5 µm	Piston
PRECI-DIP SA 811-S1-023-10-017101	Brass	1	Gold	2.54 mm	0.1 in		Through Hole	19.7 µin	0.5 µm	Piston	23
PRECI-DIP SA 811-S1-028-10-016101	Brass	1	Gold	2.54 mm	0.1 in	28	Through Hole	19.7 µin	0.5 µm	Piston
PRECI-DIP SA 811-S1-010-30-017101	Brass	1	Gold	2.54 mm	0.1 in	10	Surface Mount	19.7 µin	0.5 µm	Piston
PRECI-DIP SA 811-S1-054-10-016101	Brass	1	Gold	2.54 mm	0.1 in	54	Through Hole	19.7 µin	0.5 µm	Piston
PRECI-DIP SA 811-S1-016-10-016101	Brass	1	Gold	2.54 mm	0.1 in	16	Through Hole	19.7 µin	0.5 µm	Piston
PRECI-DIP SA 811-S1-049-10-014101	Brass	1	Gold	2.54 mm	0.1 in	49	Through Hole	19.7 µin	0.5 µm	Piston
PRECI-DIP SA 811-S1-011-10-016101	Brass	1	Gold	2.54 mm	0.1 in		Through Hole	19.7 µin	0.5 µm	Piston		11
PRECI-DIP SA 811-S1-013-10-014101	Brass	1	Gold	2.54 mm	0.1 in	13	Through Hole	19.7 µin	0.5 µm	Piston
PRECI-DIP SA 811-S1-025-10-017101	Brass	1	Gold	2.54 mm	0.1 in	25	Through Hole	19.7 µin	0.5 µm	Piston

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	80	$ 9.28

General part information

16 Position Spring Piston Connector Through Hole

Technical documentation and resources

No documents available
