13R105C

Active

Murata Power Solutions Inc.

FIXED IND 1MH 330MA 2.1 OHM TH

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

13R105C

Active

Murata Power Solutions Inc.

FIXED IND 1MH 330MA 2.1 OHM TH

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	13R105C

Current Rating (Amps)	0.33 A
DC Resistance (DCR) [Max]	2.1 Ohm
Height - Seated (Max)	13.5 mm
Height - Seated (Max) [Max] [z]	0.531 "
Inductance	1 mH
Mounting Type	Through Hole
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Vertical Cylinder
Shielding	Unshielded
Size / Dimension [diameter]	9.5 mm
Size / Dimension [diameter]	0.374 "
Tolerance	10 %
Type	Wirewound

13R Series

Part	Size / Dimension [diameter]	Size / Dimension [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Height - Seated (Max) [Max] [z]	Height - Seated (Max)	Shielding	DC Resistance (DCR) [Max]	Type	Inductance	Mounting Type	Tolerance	Current Rating (Amps)	Package / Case	DC Resistance (DCR)
Murata Power Solutions Inc. 13R105C	9.5 mm	0.374 "	85 °C	-40 °C	0.531 "	13.5 mm	Unshielded	2.1 Ohm	Wirewound	1 mH	Through Hole	10 %	0.33 A	Radial Vertical Cylinder
Murata Power Solutions Inc. 13R473C	9.5 mm	0.374 "	85 °C	-40 °C	0.531 "	13.5 mm	Unshielded		Wirewound	47 µH	Through Hole	10 %	1.5 A	Radial Vertical Cylinder	110 mOhm
Murata Power Solutions Inc. 13R333C	9.5 mm	0.374 "	85 °C	-40 °C	0.531 "	13.5 mm	Unshielded	92 mOhm	Wirewound	33 µH	Through Hole	10 %	1.8 A	Radial Vertical Cylinder
Murata Power Solutions Inc. 13R335C	9.5 mm	0.374 "	85 °C	-40 °C	0.531 "	13.5 mm	Unshielded		Wirewound	3300 µH	Through Hole	10 %		Radial Vertical Cylinder
Murata Power Solutions Inc. 13R682C	9.5 mm	0.374 "	85 °C	-40 °C	0.531 "	13.5 mm	Unshielded	23 mOhm	Wirewound	6.8 µH	Through Hole	20 %	3.5 A	Radial Vertical Cylinder
Murata Power Solutions Inc. 13R222C	9.5 mm	0.374 "	85 °C	-40 °C	0.531 "	13.5 mm	Unshielded	10 mOhm	Wirewound	2.2 µH	Through Hole	20 %	5.3 A	Radial Vertical Cylinder
Murata Power Solutions Inc. 13R332C	9.5 mm	0.374 "	85 °C	-40 °C	0.531 "	13.5 mm	Unshielded		Wirewound	3.3 µH	Through Hole	20 %	4.8 A	Radial Vertical Cylinder	13 mOhm
Murata Power Solutions Inc. 13R155C	9.5 mm	0.374 "	85 °C	-40 °C	0.531 "	13.5 mm	Unshielded	3.1 Ohm	Wirewound	1.5 mH	Through Hole	10 %	0.28 A	Radial Vertical Cylinder
Murata Power Solutions Inc. 13R153C	9.5 mm	0.374 "	85 °C	-40 °C	0.531 "	13.5 mm	Unshielded		Wirewound	15 µH	Through Hole	10 %	2.5 A	Radial Vertical Cylinder	42 mOhm
Murata Power Solutions Inc. 13R104C	9.5 mm	0.374 "	85 °C	-40 °C	0.531 "	13.5 mm	Unshielded	240 mOhm	Wirewound	100 µH	Through Hole	10 %	1 A	Radial Vertical Cylinder

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 0.59
		25	$ 0.58
		50	$ 0.56
		100	$ 0.54
		250	$ 0.50
		500	$ 0.46
		1000	$ 0.45

Description

General part information

13R Series

1 mH Unshielded Wirewound Inductor 330 mA 2.1Ohm Max Radial, Vertical Cylinder
