76069-00000850-01
ActiveHoneywell Sensing and Productivity Solutions
SWITCH 90PSI SPST-NC 1/8"NPT
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 76069-00000850-01 |
|---|---|
| Maximum Pressure [Max] | 500 PSI |
| Maximum Pressure [Max] | 3447.38 kPa |
| Operating Pressure [Max] | 90 PSI |
| Operating Pressure [Max] | 620.53 kPa |
| Operating Pressure [Min] | 351.63 kPa |
| Operating Pressure [Min] | 51 PSI |
| Operating Temperature [Max] | 121 °C |
| Operating Temperature [Min] | -40 °C |
| Output Type | SPST-NC |
| Package / Case | Cylinder, Threaded |
| Port Size | 0.125 " |
| Port Size | 3.18 mm |
| Port Size | Male |
| Port Style | Threaded |
| Pressure Type | Switch |
| Termination Style | Quick Connect - 0.250" (6.3mm) |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 69.19 | |
| 5 | $ 60.19 | |||
Description
General part information
76069 Series
Pressure Sensor 51PSI ~ 90PSI (351.63kPa ~ 620.53kPa) Switch Male - 1/8" (3.18mm) NPT Cylinder, Threaded
