1182N9

Active

Hammond Manufacturing

PWR XFMR TOROIDAL 80VA CHAS MT

Search across all available documentation for this part.

Active

Hammond Manufacturing

PWR XFMR TOROIDAL 80VA CHAS MT

Technical Specifications

Parameters and characteristics for this part

Part	Current - Output (Max)	Secondary Winding(s)	Type	Termination Style	Power - Max [Max]	Size / Dimension [diameter]	Voltage - Secondary (Full Load)	Height - Seated (Max) [Max] [z]	Voltage - Primary	Weight	Weight	Mounting Type	Primary Winding(s)	Voltage - Isolation	Current - Output (Max) [Max]	Current - Output (Max) [custom]	Current - Output (Max) [custom]
Hammond Manufacturing 1182N9	4.44 A 8.88 A	Dual	Toroidal	Wire Leads	80 VA	88.9 mm	9 V 18 V	38.1 mm	117 V 234 V	952.5 g	2.1 lb	Chassis Mount	Dual	4000 Vrms
Hammond Manufacturing 1182M240		Single	Toroidal	Wire Leads	625 VA	152.4 mm	240 V	60.45 mm	117 V 234 V	5 kg	11 lbs	Chassis Mount	Dual	4000 Vrms	2.6 A
Hammond Manufacturing 1182K240		Single	Toroidal	Wire Leads	300 VA	5 in	240 V	47.75 mm	117 V 234 V	2.7 kg	6 lbs	Chassis Mount	Dual	4000 Vrms	1.25 A
Hammond Manufacturing 1182G110		Dual	Toroidal	Wire Leads	50 VA	82.55 mm	110 V 220 V	38.1 mm	117 V 234 V	680.4 g	1.5 lb	Chassis Mount	Dual	4000 Vrms		227 mA	454 mA
Hammond Manufacturing 1182Q60	6.25 A 12.5 A	Dual	Toroidal	Wire Leads	750 VA	152.4 mm	60 V 120 V	73.15 mm	117 V 234 V	5.9 kg	13 lbs	Chassis Mount	Dual	4000 Vrms
Hammond Manufacturing 1182V24	20.8 A 41.6 A	Dual	Toroidal	Wire Leads	1000 VA	158.75 mm	24 V 48 V	73.15 mm	117 V 234 V	7.7 kg	17 lbs	Chassis Mount	Dual	4000 Vrms

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

PWR XFMR TOROIDAL 80VA CHAS MT
