851-87-046-30-001101

Active

PRECI-DIP SA

CONN SOCKET 46POS 0.05 GOLD SMD

Deep-Dive with AI

Search across all available documentation for this part.

851-87-046-30-001101

Active

PRECI-DIP SA

CONN SOCKET 46POS 0.05 GOLD SMD

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	851-87-046-30-001101

Connector Type	Socket
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	Flash
Contact Material	Beryllium Copper
Contact Shape	Circular
Contact Type	Female Socket
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	5.16 mm
Insulation Height	0.203 in
Insulation Material	Polyester, Glass Filled, Polycyclohexylenedimethylene Terephthalate (PCT)
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions	46
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating	0.05 in
Pitch - Mating	1.27 mm
Termination	Solder

851-87 Series

...

Part	Number of Positions	Contact Type	Termination	Contact Finish - Post	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Material	Pitch - Mating	Pitch - Mating	Contact Shape	Contact Finish - Mating	Mounting Type	Insulation Height	Insulation Height	Contact Finish Thickness - Mating	Contact Material	Material Flammability Rating	Number of Positions Loaded	Number of Rows	Insulation Color	Fastening Type	Contact Length - Post	Contact Length - Post
PRECI-DIP SA 851-87-011-40-252191	11	Female Socket	Solder	Tin	Socket	-55 °C	125 °C	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.05 in	1.27 mm	Circular	Gold	Surface Mount Right Angle	0.087 "	2.2 mm	Flash	Beryllium Copper	UL94 V-0	All	1	Black	Push-Pull
PRECI-DIP SA 851-87-035-40-252101	35	Female Socket	Solder	Tin	Socket	-55 °C	125 °C	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.05 in	1.27 mm	Circular	Gold	Surface Mount Right Angle	0.087 "	2.2 mm	Flash	Beryllium Copper	UL94 V-0	All	1	Black	Push-Pull
PRECI-DIP SA 851-87-025-40-252101		Female Socket	Solder	Tin	Socket	-55 °C	125 °C	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.05 in	1.27 mm	Circular	Gold	Surface Mount Right Angle	0.087 "	2.2 mm	Flash	Beryllium Copper	UL94 V-0	All	1	Black	Push-Pull
PRECI-DIP SA 851-87-038-20-001101	38	Female Socket	Solder	Tin	Socket	-55 °C	125 °C	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.05 in	1.27 mm	Circular	Gold	Through Hole Right Angle	0.087 "	2.2 mm	Flash	Beryllium Copper	UL94 V-0	All	1	Black	Push-Pull	0.118 in	3 mm
PRECI-DIP SA 851-87-020-40-252101	20	Female Socket	Solder	Tin	Socket	-55 °C	125 °C	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.05 in	1.27 mm	Circular	Gold	Surface Mount Right Angle	0.087 "	2.2 mm	Flash	Beryllium Copper	UL94 V-0	All	1	Black	Push-Pull
PRECI-DIP SA 851-87-046-30-001101	46	Female Socket	Solder	Tin	Socket	-55 °C	125 °C	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.05 in	1.27 mm	Circular	Gold	Surface Mount	0.203 in	5.16 mm	Flash	Beryllium Copper	UL94 V-0	All	1	Black	Push-Pull
PRECI-DIP SA 851-87-017-30-001101		Female Socket	Solder	Tin	Socket	-55 °C	125 °C	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.05 in	1.27 mm	Circular	Gold	Surface Mount	0.203 in	5.16 mm	Flash	Beryllium Copper	UL94 V-0	All	1	Black	Push-Pull
PRECI-DIP SA 851-87-015-20-001101	15	Female Socket	Solder	Tin	Socket	-55 °C	125 °C	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.05 in	1.27 mm	Circular	Gold	Through Hole Right Angle	0.087 "	2.2 mm	Flash	Beryllium Copper	UL94 V-0	All	1	Black	Push-Pull	0.118 in	3 mm
PRECI-DIP SA 851-87-036-40-001101	36	Female Socket	Solder	Tin	Socket	-55 °C	125 °C	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.05 in	1.27 mm	Circular	Gold	Surface Mount Right Angle	0.087 "	2.2 mm	Flash	Beryllium Copper	UL94 V-0	All	1	Black	Push-Pull
PRECI-DIP SA 851-87-018-40-252101	18	Female Socket	Solder	Tin	Socket	-55 °C	125 °C	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.05 in	1.27 mm	Circular	Gold	Surface Mount Right Angle	0.087 "	2.2 mm	Flash	Beryllium Copper	UL94 V-0	All	1	Black	Push-Pull

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	90	$ 7.51

Description

General part information

851-87 Series

46 Position Socket Connector 0.050" (1.27mm) Surface Mount Gold

Documents

Technical documentation and resources

No documents available
