Q-2I0030005009F

Active

Amphenol Custom Cable

CBL ASSY BNC-NTYPE JACK-PLUG 9'

Deep-Dive with AI

Search across all available documentation for this part.

Q-2I0030005009F

Active

Amphenol Custom Cable

CBL ASSY BNC-NTYPE JACK-PLUG 9'

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q-2I0030005009F

1st Connector	BNC Jack
1st Connector Mounting Type	Free Hanging (In-Line)
1st Contact Gender	Female
2nd Connector	N-Type Plug
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Male
Cable Impedance	50 Ohms
Cable Type	RG-316
Color	Copper
Connector Impedance	50 Ohms
Features	Shielded
Frequency - Max [Max]	3 GHz
Length	2.7 m
Length	9 ft
Length	108 in
Overall Impedance	50 Ohms
Style	BNC to N-Type

Q-2I0030 Series

Part	1st Contact Gender	Cable Impedance	Color	2nd Connector	2nd Contact Gender	Connector Impedance	2nd Connector Mounting Type	Cable Type	Overall Impedance	Frequency - Max [Max]	1st Connector Mounting Type	Features	Length	Length	Style	1st Connector	Length
Amphenol Custom Cable Q-2I0030005001F	Female	50 Ohms	Copper	N-Type Plug	Male	50 Ohms	Free Hanging (In-Line)	RG-316	50 Ohms	3 GHz	Free Hanging (In-Line)	Shielded	12 "	304.8 mm	BNC to N-Type	BNC Jack
Amphenol Custom Cable Q-2I0030005009F	Female	50 Ohms	Copper	N-Type Plug	Male	50 Ohms	Free Hanging (In-Line)	RG-316	50 Ohms	3 GHz	Free Hanging (In-Line)	Shielded	108 in	2.7 m	BNC to N-Type	BNC Jack	9 ft
Amphenol Custom Cable Q-2I0030005005F	Female	50 Ohms	Copper	N-Type Plug	Male	50 Ohms	Free Hanging (In-Line)	RG-316	50 Ohms	3 GHz	Free Hanging (In-Line)	Shielded	5 '	1.5 m	BNC to N-Type	BNC Jack	5 ft
Amphenol Custom Cable Q-2I0030005007F	Female	50 Ohms	Copper	N-Type Plug	Male	50 Ohms	Free Hanging (In-Line)	RG-316	50 Ohms	3 GHz	Free Hanging (In-Line)	Shielded	84 in	2.1 m	BNC to N-Type	BNC Jack	7 ft
Amphenol Custom Cable Q-2I0030005002F	Female	50 Ohms	Copper	N-Type Plug	Male	50 Ohms	Free Hanging (In-Line)	RG-316	50 Ohms	3 GHz	Free Hanging (In-Line)	Shielded	24 "	609.6 mm	BNC to N-Type	BNC Jack
Amphenol Custom Cable Q-2I0030005002M	Female	50 Ohms	Copper	N-Type Plug	Male	50 Ohms	Free Hanging (In-Line)	RG-316	50 Ohms	3 GHz	Free Hanging (In-Line)	Shielded	78.7 in	2 m	BNC to N-Type	BNC Jack	6.6 ft
Amphenol Custom Cable Q-2I0030005003M	Female	50 Ohms	Copper	N-Type Plug	Male	50 Ohms	Free Hanging (In-Line)	RG-316	50 Ohms	3 GHz	Free Hanging (In-Line)	Shielded	118.1 in	3 m	BNC to N-Type	BNC Jack	9.8 '
Amphenol Custom Cable Q-2I00300051.5M	Female	50 Ohms	Copper	N-Type Plug	Male	50 Ohms	Free Hanging (In-Line)	RG-316	50 Ohms	3 GHz	Free Hanging (In-Line)	Shielded	59.1 in	1.5 m	BNC to N-Type	BNC Jack	4.9 ft

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 129.26
		25	$ 126.72
		50	$ 124.18
		100	$ 121.63
		250	$ 119.09

Description

General part information

Q-2I0030 Series

Cable Assembly Coaxial BNC to N-Type RG-316 108.0" (2.7m) 9.0'

Documents

Technical documentation and resources

No documents available
