HRP-600-5

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 5V 600W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

HRP-600-5

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 5V 600W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	HRP-600-5

Applications	ITE (Commercial)
Approval Agency	CB, CE, cURus, TUV
Current - Output 1	120 A
Features	Universal Input, Remote Sense, Adjustable Output, PFC
Minimum Load Required	False
Mounting Type	Chassis Mount
Number of Outputs	1
Power (Watts)	600 W
Size / Dimension [x]	218 mm
Size / Dimension [x]	8.58 "
Size / Dimension [y]	4.13 in
Size / Dimension [y]	105 mm
Size / Dimension [z]	2.5 in
Size / Dimension [z]	63.5 mm
Type	Enclosed
Voltage - Input [Max]	370 VDC, 264 VAC
Voltage - Input [Min]	85 VAC, 120 VDC
Voltage - Isolation	3000 V
Voltage - Output 1	5 V

HRP-600 Series

Part	Voltage - Output 1	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Power (Watts)	Mounting Type	Voltage - Input [Min]	Voltage - Input [Max]	Type	Applications	Voltage - Isolation	Approval Agency	Features	Number of Outputs	Current - Output 1	Standard Number	Size / Dimension [y]	Size / Dimension [z]	Efficiency
MEAN WELL USA Inc. HRP-600-5	5 V	4.13 in	218 mm	8.58 "	2.5 in	63.5 mm	105 mm	600 W	Chassis Mount	85 VAC 120 VDC	264 VAC 370 VDC	Enclosed	ITE (Commercial)	3000 V	CB CE cURus TUV	Adjustable Output PFC Remote Sense Universal Input	1	120 A
MEAN WELL USA Inc. HRP-600N-12	12 V		8.58 in 218 mm					636 W	Chassis Mount	85 VAC 120 VDC	264 VAC 370 VDC	Enclosed	ITE (Commercial)	3000 V	CB CE cURus EAC TUV	Adjustable Output PFC Remote Sense Universal Input	1	53 A	62368-1	4.13 in 105 mm	2.42 in 61.5 mm	88 %
MEAN WELL USA Inc. HRP-600-3.3	3.3 V	4.13 in	218 mm	8.58 "	2.5 in	63.5 mm	105 mm	396 W	Chassis Mount	85 VAC 120 VDC	264 VAC 370 VDC	Enclosed	ITE (Commercial)	3000 V	CB CE cURus TUV	Adjustable Output PFC Remote Sense Universal Input	1	120 A				78.5 %
MEAN WELL USA Inc. HRP-600N-36	36 V		8.58 in 218 mm					630 W	Chassis Mount	85 VAC 120 VDC	264 VAC 370 VDC	Enclosed	ITE (Commercial)	3000 V	CB CE cURus EAC TUV	Adjustable Output PFC Remote Sense Universal Input	1	17.5 A	62368-1	4.13 in 105 mm	2.42 in 61.5 mm	89 %
MEAN WELL USA Inc. HRP-600-15	15 V	4.13 in	218 mm	8.58 "	2.5 in	63.5 mm	105 mm	645 W	Chassis Mount	85 VAC 120 VDC	264 VAC 370 VDC	Enclosed	ITE (Commercial)	3000 V	CB CE cURus TUV	Adjustable Output PFC Remote Sense Universal Input	1	43 A				88 %
MEAN WELL USA Inc. HRP-600-7.5	7.5 V	4.13 in	218 mm	8.58 "	2.5 in	63.5 mm	105 mm	600 W	Chassis Mount	85 VAC 120 VDC	264 VAC 370 VDC	Enclosed	ITE (Commercial)	3000 V	CB CE cURus TUV	Adjustable Output PFC Remote Sense Universal Input	1					87 %
MEAN WELL USA Inc. HRP-600-24	24 V	4.13 in	218 mm	8.58 "	2.5 in	63.5 mm	105 mm	648 W	Chassis Mount	85 VAC 120 VDC	264 VAC 370 VDC	Enclosed	ITE (Commercial)	3000 V	CB CE cURus TUV	Adjustable Output PFC Remote Sense Universal Input	1	27 A				88 %
MEAN WELL USA Inc. HRP-600N-24	24 V		8.58 in 218 mm					648 W	Chassis Mount	85 VAC 120 VDC	264 VAC 370 VDC	Enclosed	ITE (Commercial)	3000 V	CB CE cURus EAC TUV	Adjustable Output PFC Remote Sense Universal Input	1	27 A	62368-1	4.13 in 105 mm	2.42 in 61.5 mm	88 %

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 158.88
		5	$ 149.68
		10	$ 145.88
		25	$ 141.01

Description

General part information

HRP-600 Series

Enclosed AC DC Converters 1 Output 5V 85 ~ 264 VAC, 120 ~ 370 VDC Input
