FAG.3B.306.CYC

Active

LEMO

CONN PLUG MALE 6POS GOLD CRIMP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

FAG.3B.306.CYC

Active

LEMO

CONN PLUG MALE 6POS GOLD CRIMP

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	FAG.3B.306.CYC

Color	Silver
Connector Type	Plug, Male Pins
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	1 µm
Contact Finish Thickness - Mating	39.4 µin
Contact Material	Brass
Current Rating (Amps)	17 A
Fastening Type	Push-Pull
Ingress Protection	IP50
Insert Material	Polyetheretherketone (PEEK)
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Rear Side Nut
Number of Positions	6
Operating Temperature [Max]	250 °C
Operating Temperature [Min]	-55 °C
Orientation	G
Primary Material	Metal
Shell Finish	Chrome
Shell Material	Brass
Shell Size - Insert	306
Shielding	Shielded
Termination	Crimp

FAG.3B Series

Part	Contact Material	Fastening Type	Shell Size - Insert	Color	Insert Material	Contact Finish - Mating	Shell Material	Number of Positions	Connector Type	Shielding	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Shell Finish	Primary Material	Current Rating (Amps)	Orientation	Ingress Protection	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Mounting Feature	Material Flammability Rating	Housing Color	Body Finish	Contact Termination	Impedance	Shield Termination	Mating Cycles	Center Contact Plating	Body Material	Dielectric Material	Number of Ports	Cable Group	Connector Style
LEMO FAG.3B.306.CYC	Brass	Push-Pull	306	Silver	Polyetheretherketone (PEEK)	Gold	Brass	6	Male Pins Plug	Shielded	1 µm	39.4 µin	Chrome	Metal	17 A	G	IP50	-55 °C	250 °C	Crimp	Bulkhead - Rear Side Nut	UL94 V-0
LEMO FAG.3B.314.CLA	Brass	Push-Pull	314	Silver	Polyetheretherketone (PEEK)	Gold	Brass	14	Male Pins Plug	Shielded	1 µm	39.4 µin	Chrome	Metal	9 A	G	IP50	-55 °C	250 °C		Bulkhead - Rear Side Nut	UL94 V-0
LEMO FAG.3B.302.CLA	Brass	Push-Pull	302	Silver	Polyetheretherketone (PEEK)	Gold	Brass	2	Male Pins Plug	Shielded	1 µm	39.4 µin	Chrome	Metal	35 A	G	IP50	-55 °C	250 °C		Bulkhead - Rear Side Nut	UL94 V-0
LEMO FAG.3B.243.CLC2		Push-Pull							Male Pin Plug								IP50	-55 °C	250 °C		Bulkhead - Rear Side Nut		Silver	Chrome	Solder Cup	50 Ohms	Crimp	5000	Gold	Brass	Polyetheretherketone (PEEK)	1	196A RG-178B	Coaxial
LEMO FAG.3B.312.CLA	Brass	Push-Pull	312	Silver	Polyetheretherketone (PEEK)	Gold	Brass	12	Male Pins Plug	Shielded	1 µm	39.4 µin	Chrome	Metal	9 A	G	IP50	-55 °C	250 °C		Bulkhead - Rear Side Nut	UL94 V-0
LEMO FAG.3B.324.CLA	Brass	Push-Pull	324	Silver	Polyetheretherketone (PEEK)	Gold	Brass	24	Male Pins Plug	Shielded	1 µm	39.4 µin	Chrome	Metal	4 A	G	IP50	-55 °C	250 °C		Bulkhead - Rear Side Nut	UL94 V-0
LEMO FAG.3B.304.CYC	Brass	Push-Pull	304	Silver	Polyetheretherketone (PEEK)	Gold	Brass	4	Male Pins Plug	Shielded	1 µm	39.4 µin	Chrome	Metal	19 A	G	IP50	-55 °C	250 °C	Crimp	Bulkhead - Rear Side Nut	UL94 V-0

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 69.38
		10	$ 63.67
		25	$ 61.22
		50	$ 59.18
		100	$ 55.92

Description

General part information

FAG.3B Series

6 Position Circular Connector Plug, Male Pins Crimp
