PRF20-Q110-S15N

Active

CUI Inc.

DC DC CONVERTER 15V 20W

Search across all available documentation for this part.

Active

CUI Inc.

DC DC CONVERTER 15V 20W

Technical Specifications

Parameters and characteristics for this part

Part	Approval Agency	Features	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Standard Number	Current - Output (Max) [Max]	Voltage - Isolation	Power (Watts)	Voltage - Input (Min) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output 1	Type	Mounting Type	Applications	Voltage - Input (Max) [Max]	Control Features	Package / Case	Number of Outputs	Efficiency	Voltage - Output 2	Current - Output (Max)	Current - Output (Max)
CUI Inc. PRF20-Q110-S15N	UL	OCP OVP Remote On/Off SCP UVLO	25.4 mm	0.4 "	2 in	10.2 mm	50.8 mm	25.4 mm	60950-1	1.33 A	2250 VDC	20 W	43 V	85 °C	-40 °C	15 V	Isolated Module	Through Hole	ITE (Commercial)	160 V	Active Low Enable	6-DIP Module	1
CUI Inc. PRF20-Q110-D12	UL	OCP OVP Remote On/Off SCP UVLO	25.4 mm	0.4 "	2 in	10.2 mm	50.8 mm	25.4 mm	60950-1		2250 VDC	20 W	43 V	85 °C	-40 °C	12 V	Isolated Module	Through Hole	ITE (Commercial)	160 V	Active High Enable	6-DIP Module	2	89 %	-12 V	833 mA	833 mA
CUI Inc. PRF20-Q110-S15	UL	OCP OVP Remote On/Off SCP UVLO	25.4 mm	0.4 "	2 in	10.2 mm	50.8 mm	25.4 mm	60950-1	1.33 A	2250 VDC	20 W	43 V	85 °C	-40 °C	15 V	Isolated Module	Through Hole	ITE (Commercial)	160 V	Active High Enable	6-DIP Module	1
CUI Inc. PRF20-Q110-S12N	UL	OCP OVP Remote On/Off SCP UVLO	25.4 mm	0.4 "	2 in	10.2 mm	50.8 mm	25.4 mm	60950-1	1.67 A	2250 VDC	20 W	43 V	85 °C	-40 °C	12 V	Isolated Module	Through Hole	ITE (Commercial)	160 V	Active Low Enable	6-DIP Module	1	90 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	50	$ 89.25

General part information

Isolated Module DC DC Converter 1 Output 15V 1.33A 43V - 160V Input

Technical documentation and resources

No documents available
