BXRC-30E4000-C-83-SE

Active

BRIDGELUX

LED COB VERO SE18C WH RND 3000K

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

BXRC-30E4000-C-83-SE

Active

BRIDGELUX

LED COB VERO SE18C WH RND 3000K

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	BXRC-30E4000-C-83-SE

CCT (K)	3000 K
Color	White, Warm
Configuration	Round
CRI (Color Rendering Index)	80
Current - Max [Max]	3 A
Current - Test	1.05 A
Height [z]	3.6 mm
Lens Type	Flat
Light Emitting Surface (LES) [diameter]	18.5 mm
Lumens/Watt @ Current - Test	177 lm/W
Luminous Flux @ Current/Temperature	6317 lm
Size / Dimension [diameter]	36.2 mm
Type	Chip On Board (COB)
Viewing Angle	120 °
Voltage - Forward (Vf) (Typ)	33.9 V

BXRC-30 Series

...

Part	Viewing Angle	Light Emitting Surface (LES) [diameter]	Height [z]	CRI (Color Rendering Index)	Lumens/Watt @ Current - Test	Type	Luminous Flux @ Current/Temperature	Color	Lens Type	Current - Test	Size / Dimension [diameter]	Features	Configuration	CCT (K)	Current - Max [Max]	Voltage - Forward (Vf) (Typ)	Temperature - Test
BRIDGELUX BXRC-30E1000-B-02	120 °	9.9 mm	1.9 mm	80	120 lm/W	Chip On Board (COB)	1120 lm	Warm White	Flat	350 mA	20 mm	With Connector	Starboard	3000 K	700 mA	26.7 V
BRIDGELUX BXRC-30H10K0-C-83	120 °	29.1 mm	1.9 mm	97	136 lm/W	Chip On Board (COB)	11796 lm	Warm White	Flat	1.3 A	49.2 mm		Round	3000 K	4.75 A	66.7 V
BRIDGELUX BXRC-30H1000-C-83	120 °	10 mm	1.8 mm	97		Chip On Board (COB)		Warm White	Flat	300 mA	20 mm		Starboard	3000 K	1 A	30.7 V
BRIDGELUX BXRC-30G1000-D-73	120 °	9.9 mm	1.9 mm	90	129 lm/W	Chip On Board (COB)	1172 lm	Warm White	Flat	350 mA	20 mm	With Connector	Starboard	3000 K	700 mA	26 V
BRIDGELUX BXRC-30E1000-C-73	120 °	9.9 mm	1.9 mm	80	155 lm/W	Chip On Board (COB)	1936 lm	Warm White	Flat	360 mA	20 mm	With Connector	Starboard	3000 K	720 mA	34.8 V
BRIDGELUX BXRC-30C10K1-C-84-SE	120 °	29.1 mm	3.6 mm	70	193 lm/W	Chip On Board (COB)	16756 lm	Warm White	Flat	1.3 A	49.2 mm		Round	3000 K	4.75 A	66.7 V
BRIDGELUX BXRC-30E4000-C-83-SE	120 °	18.5 mm	3.6 mm	80	177 lm/W	Chip On Board (COB)	6317 lm	Warm White	Flat	1.05 A	36.2 mm		Round	3000 K	3 A	33.9 V
BRIDGELUX BXRC-30G1000-B-22	120 °	9.9 mm	1.9 mm	90	110 lm/W	Chip On Board (COB)	1021 lm	Warm White	Flat	350 mA	20 mm	With Connector	Starboard	3000 K	700 mA	26.5 V
BRIDGELUX BXRC-30G1000-B-03	120 °	9.9 mm	1.9 mm	90	98 lm/W	Chip On Board (COB)	915 lm	Warm White	Flat	350 mA	20 mm	With Connector	Starboard	3000 K	700 mA	26.7 V
BRIDGELUX BXRC-30A4001-D-73-SE	120 °	18.4 mm	3.6 mm	93	109 lm/W	Chip On Board (COB)	3234 lm	Warm White	Flat	1.05 A	36.2 mm		Round	3000 K	2.1 A	28.3 V	85 °C

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1	$ 16.50
		10	$ 12.44
		80	$ 10.45
		440	$ 9.60
		945	$ 9.07

Description

General part information

BXRC-30 Series

LED Lighting COBs Engines Modules Chip On Board (COB) Gen 8 Vero® SE 18 Array White, Warm Round
