4-1415540-6

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE DPDT 8A 24V

Search across all available documentation for this part.

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE DPDT 8A 24V

Technical Specifications

Parameters and characteristics for this part

Specification	4-1415540-6

Approval Agency	cURus, VDE
Coil Current	16.7 mA
Coil Resistance	350 Ohms
Coil Type	Non Latching
Coil Voltage	24 VAC
Contact Form	DPDT (2 Form C)
Contact Material	Silver Nickel (AgNi)
Contact Rating (Current)	8 A
Features	Lighted Indicator, Socket Included
Load - Max Switching	3200 VA
Mounting Type	DIN Rail
Must Operate Voltage	18 VAC
Must Release Voltage	3.6 VAC
Operate Time	9 ms
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-40 °C
Relay Type	General Purpose
Release Time	6 ms
Switching Voltage [Max]	400 VAC
Termination Style	Screw Terminal

Part	Features	Operating Temperature [Min]	Operating Temperature [Max]	Must Release Voltage	Approval Agency	Switching Voltage [Max]	Coil Type	Termination Style	Relay Type	Coil Current	Coil Resistance	Mounting Type	Coil Voltage	Release Time	Contact Form	Load - Max Switching	Contact Rating (Current)	Contact Material	Operate Time	Must Operate Voltage
TE Connectivity Potter & Brumfield Relays 4-1415540-6	Lighted Indicator Socket Included	-40 °C	70 °C	3.6 VAC	cURus VDE	400 VAC	Non Latching	Screw Terminal	General Purpose	16.7 mA	350 Ohms	DIN Rail	24 VAC	6 ms	DPDT (2 Form C)	3200 VA	8 A	Silver Nickel (AgNi)	9 ms	18 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

General Purpose Relay DPDT (2 Form C) 24VAC Coil DIN Rail
