VLDTG1232G-08
ActiveVishay General Semiconductor - Diodes Division
LED GREEN DOME LENS 2SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
VLDTG1232G-08
ActiveVishay General Semiconductor - Diodes Division
LED GREEN DOME LENS 2SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | VLDTG1232G-08 |
|---|---|
| Color | Green |
| Current - Test | 20 mA |
| Height (Max) [Max] [z] | 3.02 mm |
| Lens Size [diameter] | 1.8 mm |
| Lens Style | Round with Domed Top |
| Millicandela Rating | 16000 mcd |
| Mounting Type | Surface Mount |
| Package / Case | 2-SMD, Gull Wing |
| Size / Dimension [x] | 2.3 mm |
| Size / Dimension [y] | 2.3 mm |
| Supplier Device Package | 2-SMD |
| Viewing Angle | 18 ° |
| Voltage - Forward (Vf) (Typ) | 2.9 V |
| Wavelength - Dominant | 525 nm |
| Wavelength - Peak | 519 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.67 | |
| 10 | $ 0.44 | |||
| 100 | $ 0.29 | |||
| Digi-Reel® | 1 | $ 0.67 | ||
| 10 | $ 0.44 | |||
| 100 | $ 0.29 | |||
| Tape & Reel (TR) | 1500 | $ 0.23 | ||
| 3000 | $ 0.20 | |||
| 7500 | $ 0.19 | |||
| 10500 | $ 0.18 | |||
| 37500 | $ 0.18 | |||
Description
General part information
VLDTG1232 Series
Green 525nm LED Indication - Discrete 2.9V 2-SMD, Gull Wing
