AMSR1-2412Z
Activeaimtec
DC DC CONVERTER 12V 12W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AMSR1-2412Z
Activeaimtec
DC DC CONVERTER 12V 12W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AMSR1-2412Z |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 1 A |
| Efficiency | 93 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 3-SIP Module |
| Power (Watts) | 12 W |
| Size / Dimension [x] | 11.7 mm |
| Size / Dimension [x] | 0.46 in |
| Size / Dimension [y] | 0.29 " |
| Size / Dimension [y] | 7.5 mm |
| Size / Dimension [z] | 10.2 mm |
| Size / Dimension [z] | 0.4 " |
| Type | Non-Isolated PoL Module |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 15 V |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 11.47 | |
| 5 | $ 11.35 | |||
| 10 | $ 11.24 | |||
| 15 | $ 11.13 | |||
| 25 | $ 11.01 | |||
| 50 | $ 10.79 | |||
| 100 | $ 10.69 | |||
| 200 | $ 10.53 | |||
| 500 | $ 10.00 | |||
Description
General part information
AMSR1 Series
Non-Isolated PoL Module DC DC Converter 1 Output 12V 1A 15V - 36V Input
Documents
Technical documentation and resources
